Monel 400 Nickel Alloy Seamless Pipe UNS N04400 DN10 - DN200 With SCH40S ASTM
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | monel 400 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Pipe | Grade | Monel 400 |
|---|---|---|---|
| Diameter | OD6 - 1020mm | Length | 6m Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Thickness | 0.5 - 40.0mm |
| Highlight | Monel 400 Nickel Alloy,Nickel Alloy Seamless Pipe |
||
Product Description
Monel 400 Nickel Alloy Seamless Pipe UNS N04400 DN10 - DN200 with SCH40S Standard ASTM
Manufacturer of Nickel 400 Annealed Pipe, View Price List of Alloy 400 Seamless Pipe
Specification Chart of Monel 400 Pipe
| ASTM Specification | ASTM B725 / ASME SB725 |
|---|---|
| Standard | ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| Monel grade 400 EFW Pipe size | 5.0 - 1219.2 mm |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Monel 400 Pipe End | Plain End, Beveled End, Treaded Pipe, Screwed ends |
| Monel 400 Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Alloy 400 Welded Pipe Size | 5.0 - 1219.2 mm |
| Marking on Monel 2.4360 Pipe | All Monel 400 Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application of Monel 400 Pipe | Dairy Pipe, Oil Pipe, Gas Pipe, Fluid Pipe, Boiler Pipe for Chemical Industry |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialize in | Large Diameter Monel 400 Pipe |
| Alloy Monel 400 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Monel 400 Pipe Length | Single Random, Double Random, Standard & Cut length Pipe |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc |
| Form | Monel 400 Pipe are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| Type of Nickel Alloy 400 Pipe | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Monel 400 Pipe |
| Monel 400 Pipe manufacturing Technique | Cold drawn, hot drawn, bright annealed, solid solution, hot extruding |
| We can also cut, thread, and groove Alloy 400 Pipe to meet your specifications. Monel 400 Pipe Dimension ANSI/ ASME B36.10, B36.19, B2.1 | |
types of Monel grade 400 Plate
| Monel 400 Pipe | 4 inch Monel grade 400 Seamless Pipes |
| Monel grade 400 Pipes | Alloy Monel 400 Welded Pipes |
| Monel 400 UNS N04400 Seamless Steel Pipes | ASTM B725 UNS N04400 Cold Drawn Welded Pipes |
| Monel grade 400 Welded Pipe | Nickel 400 Cold Drawn Pipes |
| Alloy Monel 400 ERW Pipes | Schedule 5S Monel 400 UNS N04400 Seamless Pipes |
| Nickel 400 EFW Pipes | Schedule 40 Monel Alloy 400 Pipes |
| Monel 400 UNS N04400 Cold Drawn Seamless Pipes | Alloy Monel 400 Precision Pipes |
| Monel 400 Seamless Steel Precision Pipes | High pressure Alloy 400 Pipes |
| Monel Alloy 400 Cold Drawn Seamless Pipes | Nickel Alloy 400 Electropolished Pipe |
| Monel grade 400 Custom Pipes | Monel 400 Cold Drawn Pipes |
| ASTM B725 UNS N04400 Round Pipes | Monel 2.4360 Exhaust Pipe |
| Nickel Alloy 400 Square Pipes | Alloy Monel 400 Thin Wall Pipes |
| Monel 2.4360 Rectangular Pipes | Small diameter Nickel Alloy 400 Pipes |
| Monel 400 UNS N04400 Hexagonal Pipes | Monel grade 400 Pipe material |
| Monel 400 Bush Hex Pipes | Monel Alloy 400 Precision Steel Pipes |
| Nickel 400 Fabricated Pipes | ASTM B725 UNS N04400 Annealed Pipes |
| ASTM B725 UNS N04400 Beveled End Pipes | Nickel 400 Rectangle Pipes |
| Alloy 400 Cold Drawn Pipes | Cold Drawn Monel 400 Welded Pipes |
Mechanical Characteristics of Monel 400 Pipe
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Chemical Formula of Monel 400 UNS N04400 Pipe
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
Physical Properties of Monel 400 Pipe
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Alloy Grade 2 Pipe Stock List
|
Properties
|
Metric
|
Imperial
|
|---|---|---|
|
Density
|
8.8 gm/cm3
|
0.318 lb/in3
|
Monel 400 EFW Pipe Dealer, One of India’s largest 400 Monel Cold Drawn Pipe supplier. Stockholder of Monel WERKSTOFF NR. 2.4360 Pipe, Supplier of ASTM B725 Monel 400 Welded Pipe. Monel 400 Hollow Pipe, 400 Monel Hot Finished Pipe Importer in India.
international Standard Specification of Monel Alloy 400 Pipe
| UNS: | N04400 |
| Specifications: | ASTM B165, ASTM B829, ASTM B775, ASTM B725, ASTM B163, ASTM B730, ASTM B751,ams 4574 |
| international Specifications: | din 17752, VdTUV 2635 |
Wall Thickness of 400 Alloy Pipe
| Types | Out diameter | Wall thickness | Length |
|---|---|---|---|
| NB Sizes (in stock) | 1/8” ~ 8” | SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 | Upto 6 Meters |
| monel 400 Seamless Pipe (Custom Sizes) | 5.0mm ~ 203.2mm | As per requirement | Upto 6 Meters |
| monel 400 Welded Pipe (in Stock + Custom Sizes) | 5.0mm ~ 1219.2mm | 1.0 ~ 15.0 mm | Upto 6 Meters |
