Seamless Welded Stainless Steel Pipe ASTM A790 / A213 / A312 / A270 OD6 - 406mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L 321 310S 314 347 2205 2507 904 630 L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Welded Pipe | Grade | 304 316L 321 2205 310S 904L 17-4ph.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | Random Length Of 6m |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | Seamless Stainless Steel Welded Pipe,Stainless Steel Welded Pipe 406mm,Stainless Steel A790 Pipe |
||
Product Description
ASTM A790 / A213 / A312 / A270 Stainless Steel Pipe / Seamless Pipe Welded Pipe OD6 - 406mm
| Name | stainless steel pipe |
| Standard | ASTM, GB, JIS, DIN, EN, AISI |
| Material Grade | TP304 TP304L TP316 TP316L TP347 TP347H TP321 TP321H TP310 TP310S |
| TP410 TP410S 17-4PH 254SMO 253MA | |
| S31803/S32205 S32750 S32760 | |
| Outer Diameter | Seamless Pipe: 4mm-812.80mm |
| Welded Pipe: single slit(Φ8mm-Φ630mm); girth(Φ630mm-Φ3000mm), | |
| Thickness | Seamless Pipe: 0.5mm - 60mm |
| Welded Pipe: single slit(0.5mm-25mm);girth(3mm-45mm) | |
| Length | 5.8-6.1 m or as customers' request |
| Tolerance | Acording to the Standard. |
| Surface | 180G, 320G, 400G Satin / Hairline |
| 400G, 500G, 600G or 800G Mirror finish | |
| Test | UT, ET, HT, RT,ect, and others according to the standard,or as the requests of the customers |
| Certificate | ISO9001-2008,ASME, PED |
| Delivery Time | 7-30 Days, Depends on quantity |
More Specification of our pipe
| Stainless Steel Pipe | |
| Form | Welded and Seamless in Round. |
| Application | Fluid & Decorative. |
| Size Range | DN15 – DN600. |
| Grades | 304/304L & 316/316L. |
| Wall Thickness | Sch 10S, 40S & 80S. |
| Fittings | Butt Weld, Screwed & Socket Flanges (ANSI, Table E & Table D). |
| Processing | Cut-to-length & polishing. |
Stainless Steel Piping Systems
A stainless steel pipe system is the product of choice for carrying corrosive or sanitary fluids, slurries and gases, particularly where high pressures, high temperatures or corrosive environments are involved. As a result of the aesthetic properties of stainless steel, pipe is often use in architectural applications.
Stainless steel pipe can generally be defined as a heavy wall thickness tubing, with dimensions as specified by the American National Standards Institute (ANSI). Pipe dimensions are nominated by outside diameter indicated by the NPS (imperial) or DN (metric) designator and sometimes referred to as the ‘nominal bore’ – and wall thickness, is determined by the schedule number. The standard ASME B36.19 covers these dimensions.
Stainless steel pipe and fittings are supplied in the annealed condition to facilitate fabrication and ensure best corrosion resistance. Atlas Steels can also supply stainless steel pipe with an abrasive polished finish suitable for architectural applications.
Welded pipe
Welded stainless steel pipe is manufactured from 2B or HRAP stainless steel strip – formed (to shape) and longitudinally welded to completed pipe. With the exception of very large pipe welds are made without the addition of filler metal. Standard welded pipe is in nominal lengths of 6.0 to 6.1 metres.
Manufacturing specification:
- ASTM A312M – Austenitic
- ASTM A358M – Austenitic (large diameter)
- ASTM A790M – Duplex.
Seamless Pipe
Seamless stainless steel pipe is produced from hollow billets, which are then drawn across dies until they reach the final desired pipe size and wall thickness. Standard seamless pipe is in random lengths of 6.0 to 7.5 metres.
Manufacturing specification:
- ASTM A312M – Austenitic.
- ASTM A790M – Duplex
