Raian IonescuMaterial quality very good. we have cooperate more than 10 Years. They trade lots kinds of steel material. All material quality good. They duty for all material quality. We are planing continue cooperate with them in the future
Cold Formed Steel Sheet Pile Larsen Q235 Sy295 Sy390 Metal Sheet Piling U/Z 6m 12m
| Place of Origin | CHINA |
|---|---|
| Brand Name | DETA |
| Certification | ISO |
| Model Number | Q235B Q355B |
| Minimum Order Quantity | 25 Tons |
| Price | 600 - 800 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 12-20 Days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 400Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Special Use | High-strength Steel Plate, Wear Resistant Steel, Silicon Steel, Etc. | Length | 1000-12000mm |
|---|---|---|---|
| Application | Construction, Shipbuilding, Machinery, Bridges, Etc. | Width | 1000-3000mm |
| Standard | ASTM, JIS, GB, AISI, DIN, BS | Tolerance | ±3% |
| Material | Steel | Heat Treatment | Annealing, Normalizing, Quenching, Tempering, Etc. |
| Highlight | Cold Formed Larsen Steel Sheet Pile,Larsen Steel Q235 Sheet Pile,12m Larsen Steel Sheet Pile |
||
Product Description
Cold Formed and Hot Rolled Larsen Q235 Q345 Q345b Sy295 Sy390 Metal Sheet Piling U/Z Type Steel Sheet Pile 6m 12m
Products Description
|
SPECIFICATIONS FOR SHEET PILE
|
|
|
1. Size
|
1) 400*100 - 600*210MM
|
|
2)Wall Thickness:10.5-27.6MM
|
|
|
3) U type sheet pile
|
|
|
2. Standard:
|
JIS A5523, JIS A5528
|
|
3.Material
|
SY295, SY390, S355
|
|
4. Location of our factory
|
Shandong,China
|
|
5. Usage:
|
1)earth-retaining wall
|
|
2)structure construction
|
|
|
3)fence
|
|
|
6. Coating:
|
1) Bared
2) Black Painted (varnish coating) 3) galvanized |
|
7. Technique:
|
hot rolled
|
|
8. Type:
|
U type / Z type sheet pile
|
|
9. Section Shape:
|
U Z
|
|
10. Inspection:
|
Client inspection or inspection by 3rd party.
|
|
11. Delivery:
|
Container, Bulk Vessel.
|
|
12. About Our Quality:
|
1) No damage, no bent
2) Free for oiled&marking 3) All goods can be checked by third party inspection before shipment |
Our steel sheet pile features high strength, light weight, good water-resisting performance and super durability.
Hot rolled steel sheet pile is a kind of high efficient energy saving building materials.Widely used in embankment, a loading dock, dock, temporary Island, dyke, Luqiao, temporary pier revetment revetment, waterproof cofferdam, river, embankment reinforcement, retaining wall, retaining wall and the construction foundation pit bracing structure of foundation engineering
U steel sheet pile is most common sheet pile with obvious features such as :high intensity, water-proof property and so on. In bridge construction, u steel sheet pile has gradually played an important role and been popular with engineers. Steel sheet pile from our factory owns the high-class quality, forging by the advanced technology.
U - type series cold - bending steel sheet pile legend and advantages
1) U Type steel sheet pile specifications and models are rich.
2) According to the European standard design and production, symmetrical structure form, is conducive to repeated use, in repeated use and hot rolling equivalent.
3) The length can be customized according to customer requirements, which brings great convenience to the construction and reduces the cost.
4) Due to the convenient production, it can be customized in advance when used together with the composite pile.
5) The production design and production cycle is short, and the performance of steel sheet pile can be determined according to customer requirements.
2) According to the European standard design and production, symmetrical structure form, is conducive to repeated use, in repeated use and hot rolling equivalent.
3) The length can be customized according to customer requirements, which brings great convenience to the construction and reduces the cost.
4) Due to the convenient production, it can be customized in advance when used together with the composite pile.
5) The production design and production cycle is short, and the performance of steel sheet pile can be determined according to customer requirements.
|
Size
|
Per piece
|
||||
|
Specification
|
Width
(mm)
|
High
(mm)
|
Thick
(mm)
|
Section area
(cm2)
|
Weight
(kg/m)
|
|
400 x 85
|
400
|
85
|
8.0
|
45.21
|
35.5
|
|
400 x 100
|
400
|
100
|
10.5
|
61.18
|
48.0
|
|
400 x 125
|
400
|
125
|
13.0 |
76.42
|
60.0
|
|
400 x 150
|
400
|
150
|
13.1
|
74.40
|
58.4
|
|
400 x 170
|
400
|
170
|
15.5
|
96.99
|
76.1
|
|
600 x 130
|
600
|
130
|
10.3
|
78.7
|
61.8
|
|
600 x 180
|
600
|
180
|
13.4
|
103.9
|
81.6
|
|
600 x 210
|
600
|
210
|
18.0
|
135.3
|
106.2
|
|
|
750
|
204
|
10.0
|
99.2
|
77.9
|
|
750
|
205.5
|
11.5
|
109.9
|
86.3
|
|
|
750
|
206
|
12.0
|
113.4
|
89.0
|
|
Z type steel sheet piles:
1.Flexible design, a relatively high section modulus and mass ratio.
2.The stiffness of sheet pile wall is increased to reduce the displacement and deformation.
3.Large width, effectively save the time of hoisting and piling.
4.With the increase of section width, the water stop performance is improved.
5.More excellent corrosion resistance.
2.The stiffness of sheet pile wall is increased to reduce the displacement and deformation.
3.Large width, effectively save the time of hoisting and piling.
4.With the increase of section width, the water stop performance is improved.
5.More excellent corrosion resistance.
|
Specification
|
Width
(mm)
|
High
(mm)
|
Thick t
(mm)
|
Thick s
(mm)
|
Weight
(kg/m)
|
|
SPZ12
|
700
|
314
|
8.5
|
8.5
|
67.7
|
|
SPZ13
|
700
|
315
|
9.5
|
9.5
|
74
|
|
SPZ14
|
700
|
316
|
10.5
|
10.5
|
80.3
|
|
SPZ17
|
700
|
420
|
8.5
|
8.5
|
73.1
|
|
SPZ18
|
700
|
418
|
9.10
|
9.10
|
76.9
|
|
SPZ19
|
700
|
421
|
9.5
|
9.5
|
80.0
|
|
SPZ20
|
700
|
421
|
10.0
|
10.0
|
83.5
|
|
SPZ24
|
700
|
459
|
11.2
|
11.2
|
95.7
|
|
SPZ26
|
700
|
459
|
12.3
|
12.3
|
103.3
|
|
SPZ28
|
700
|
461
|
13.2
|
13.2
|
110.0
|
|
SPZ36
|
700
|
499
|
15.0
|
11.2
|
118.6
|
|
SPZ38
|
700
|
500
|
16.0
|
12.2
|
126.4
|
|
SPZ25
|
630
|
426
|
12.0
|
11.2
|
91.5
|
|
SPZ48
|
580
|
481
|
19.1
|
15.1
|
140.2
|
U steel sheet pile is most common sheet pile with obvious features such as :high intensity, water-proof property and so on. In
bridge construction, u steel sheet pile has gradually played an important role and been popular with engineers. Steel sheet pile
from our factory owns the high-class quality, forging by the advanced technology
bridge construction, u steel sheet pile has gradually played an important role and been popular with engineers. Steel sheet pile
from our factory owns the high-class quality, forging by the advanced technology
FAQ
Q1:Where is your factory?
A:Our company's processing center is located in Shandong China.
Q2:What is your delivery time?
A:For products in stock, we can ship it within 7 days after receiving the deposit. For customer order, production time is 15-30 workdays after receiving the deposit.
Q3:Can I place an sample order and what is your MOQ if I accept your quality?
A:Yes, we can send you samples but you may pay the express fees and customized samples will take about 5-7days, our MOQ is 1 ton.
Q4:How could you guarantee your products?
A:Mill Test Certification is supplied with shipment, We also accept and support the third-party inspection.We also could issue the warranty to customer to guarantee the quality.
Q5:How can I get the price of needed product?
A:It's the best way if you can send us the material, size and surface, so we can produce for you to check the quality.If you still have any confusion, just contact us, we would like to be helpful.
Q6: Why do you want to buy from us instead of from other suppliers?
A:Our own factory, dealing in steel materials, such as steel plate, steel pipe, steel rod, steel wire, tinplate, aluminum products. Welcome to our company product exhibition, looking forward to our perfect cooperation.
Q1:Where is your factory?
A:Our company's processing center is located in Shandong China.
Q2:What is your delivery time?
A:For products in stock, we can ship it within 7 days after receiving the deposit. For customer order, production time is 15-30 workdays after receiving the deposit.
Q3:Can I place an sample order and what is your MOQ if I accept your quality?
A:Yes, we can send you samples but you may pay the express fees and customized samples will take about 5-7days, our MOQ is 1 ton.
Q4:How could you guarantee your products?
A:Mill Test Certification is supplied with shipment, We also accept and support the third-party inspection.We also could issue the warranty to customer to guarantee the quality.
Q5:How can I get the price of needed product?
A:It's the best way if you can send us the material, size and surface, so we can produce for you to check the quality.If you still have any confusion, just contact us, we would like to be helpful.
Q6: Why do you want to buy from us instead of from other suppliers?
A:Our own factory, dealing in steel materials, such as steel plate, steel pipe, steel rod, steel wire, tinplate, aluminum products. Welcome to our company product exhibition, looking forward to our perfect cooperation.
