Hot Rolled Steel Sheet Pile / U Type Z Type Thickness 2.0 - 14.0mm
| Place of Origin | CHINA |
|---|---|
| Brand Name | DETA |
| Certification | ISO |
| Model Number | Q235B Q355B |
| Minimum Order Quantity | 25 Tons |
| Price | 600 - 800 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 12-20 Days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 400Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Special Use | High-strength Steel Plate, Wear Resistant Steel, Silicon Steel, Etc. | Length | 1000-12000mm |
|---|---|---|---|
| Application | Construction, Shipbuilding, Machinery, Bridges, Etc. | Width | 1000-3000mm |
| Standard | ASTM, JIS, GB, AISI, DIN, BS | Tolerance | ±3% |
| Material | Steel | Heat Treatment | Annealing, Normalizing, Quenching, Tempering, Etc. |
| Highlight | Hot Rolled Steel Sheet Pile,14.0 mm Steel Plate Pile,Steel Plate Pile 3000mm |
||
Product Description
Hot Rolled Steel Sheet Pile / U Type Z Type Steel Sheet Pile Thickness 2.0 - 14.0mm
Product Description
Our steel sheet pile features high strength, light weight, good water-resisting performance and super durability.
Hot rolled steel sheet pile is a kind of high efficient energy saving building materials.Widely used in embankment, a loading dock, dock, temporary Island, dyke, Luqiao, temporary pier revetment revetment, waterproof cofferdam, river, embankment reinforcement, retaining wall, retaining wall and the construction foundation pit bracing structure of foundation engineering
U steel sheet pile is most common sheet pile with obvious features such as :high intensity, water-proof property and so on. In bridge construction, u steel sheet pile has gradually played an important role and been popular with engineers. Steel sheet pile from our factory owns the high-class quality, forging by the advanced technology.
U type steel sheet piles:
Z type steel sheet piles:
Hot rolled steel sheet pile is a kind of high efficient energy saving building materials.Widely used in embankment, a loading dock, dock, temporary Island, dyke, Luqiao, temporary pier revetment revetment, waterproof cofferdam, river, embankment reinforcement, retaining wall, retaining wall and the construction foundation pit bracing structure of foundation engineering
U steel sheet pile is most common sheet pile with obvious features such as :high intensity, water-proof property and so on. In bridge construction, u steel sheet pile has gradually played an important role and been popular with engineers. Steel sheet pile from our factory owns the high-class quality, forging by the advanced technology.
U type steel sheet piles:
| Size | Per piece | ||||
| Specification | Width (mm) |
High (mm) |
Thick (mm) |
Section area (cm2) |
Weight (kg/m) |
| 400 x 85 | 400 | 85 | 8.0 | 45.21 | 35.5 |
| 400 x 100 | 400 | 100 | 10.5 | 61.18 | 48.0 |
| 400 x 125 | 400 | 125 | 13.0 | 76.42 | 60.0 |
| 400 x 150 | 400 | 150 | 13.1 | 74.40 | 58.4 |
| 400 x 170 | 400 | 170 | 15.5 | 96.99 | 76.1 |
| 600 x 130 | 600 | 130 | 10.3 | 78.7 | 61.8 |
| 600 x 180 | 600 | 180 | 13.4 | 103.9 | 81.6 |
| 600 x 210 | 600 | 210 | 18.0 | 135.3 | 106.2 |
| 750 x 205 | 750 | 204 | 10.0 | 99.2 | 77.9 |
| 750 | 205.5 | 11.5 | 109.9 | 86.3 | |
| 750 | 206 | 12.0 | 113.4 | 89.0 | |
| Specification | Width (mm) |
High (mm) |
Thick t (mm) |
Thick s (mm) |
Weight (kg/m) |
| SPZ12 | 700 | 314 | 8.5 | 8.5 | 67.7 |
| SPZ13 | 700 | 315 | 9.5 | 9.5 | 74 |
| SPZ14 | 700 | 316 | 10.5 | 10.5 | 80.3 |
| SPZ17 | 700 | 420 | 8.5 | 8.5 | 73.1 |
| SPZ18 | 700 | 418 | 9.10 | 9.10 | 76.9 |
| SPZ19 | 700 | 421 | 9.5 | 9.5 | 80.0 |
| SPZ20 | 700 | 421 | 10.0 | 10.0 | 83.5 |
| SPZ24 | 700 | 459 | 11.2 | 11.2 | 95.7 |
| SPZ26 | 700 | 459 | 12.3 | 12.3 | 103.3 |
| SPZ28 | 700 | 461 | 13.2 | 13.2 | 110.0 |
| SPZ36 | 700 | 499 | 15.0 | 11.2 | 118.6 |
| SPZ38 | 700 | 500 | 16.0 | 12.2 | 126.4 |
| SPZ25 | 630 | 426 | 12.0 | 11.2 | 91.5 |
| SPZ48 | 580 | 481 | 19.1 | 15.1 | 140.2 |
Application
1. Wharf wall, noise isolation wall, etc. Used in hydraulic engineering.
2.Used for wall protection and parking equipment in waterway civil engineering.
3.Used for the control of water conservancy project construction pollution.
FAQ
Q1:How about thequality?
A:Third party inspections are always welcomed, like TUV. All of the goods will be released together with MTC and stamped by TPI.
Q2: How long is the delivery time?
A: Generally about 5-10 days if the goods in stock. Or will be 15-20 days if the goods are not in stock. And alsoaccording to the quantity.
Q3:Do you provide samples? Free or not?
A: Yes, we could offer the sample for free but do not pay the cost of freight.
Q4:May I customize the steel pipe?
A:Sure you can, we can produce according to your requirement, you can send the CAD ordesign drawing.
Q5:Any value-added Services?
A:Fottunately for you,we are very experience in this industry. We have equipped our warehouse with the necessitiesto perform in-house painting,coating,pipe cutting, jointed welding, and make machanical fabricate per to request.
Q6: How about the trade terms?
A: EXW, FOB, CFR, CIF, LC will be accepted.
