Z Type Hot Rolled Steel Sheet Pile Thickness 6.0mm 8.0mm 10.0mm Grade Q355B Q235B

Z Type Hot Rolled Steel Sheet Pile Thickness 6.0mm 8.0mm 10.0mm Grade Q355B Q235B

Z profile steel sheet piles are call Z because one single sheet pile stands like the letter. Cold formed sheet piling is also produced through a series of rollers, by which the Z shape is formed gradually with uniform thickness along the full length of the profiles. The thinnest Z type sheet piling might be only 3mm thickness. 15 years ago, cold rolled sheet piling manufacturer was only in Europe, today most sheet piling is produced in China, especially heavy gauge sections. Clutches are located on both sides far from the neutral axis, which provide maximum use of the materials and also good for a bigger modulus of section. Like all other cold rolled metal sheet piles, Z sections can also be produce in any possible width, height, thickness. OZ sheet pile, PAZ sheet pile, all other sheet piling specifications and dimensions are all no problem. Different from hot rolling technology, in which the profiles can form the shape in mills, cold forming needs another process of rolling and forming, the maximum thickness for cold rolled Z type sheet pile is 16mm.

Sheet piling design and calculation can be done from the very beginning, our factory can tailor make the dimensions and specifications for projects, you can know the total costs from the very beginning . Any steel grade all can be used, S235 S355 S390 S430 S460 etc is only a matter of request. In Asia, U type steel sheet pile is still the tradition, but more and more jobs, especially wharf constructions, deep foundations, seawall, bulkheads requires Z sizes. Now in Europe, especially western Europe, sheet pile contractors prefer Z profiles. HZ combined wall,OZ sheet piles and tubular combined walls all use Z types.

Z type sheet piles are produced in zigzag form and are usually driven in crimped or welded doubles.

Z type sheet piles are more widely used than U-type piles in port construction and deep foundations

because Z type sheets can have greater modulus and can be used as intermediate piles in tubular & HZ combination walls.

Advantage of Z type steel sheet pile:

1. Flexible design, high section modulus, and mass ratio;

2. Higher moment of inertia increases the stiffness of sheet pile wall and reduces the displacement deformation;

3. Large width, effectively saving the time of lifting and piling;

4. Thickening treatment is carried out in the parts with serious corrosion, and the corrosion resistance is excellent.

6. The weight per square meter of a Z sheet pile is always less than that of a U sheet pile for a similar section modulus.

7. It can be used as an infill pile together with steel pipes and H-beams, and is usually used to obtain a very high modulus.

Application of Z type steel sheet pile:

The steel sheet pile is very wide, in the permanent structure of the building, can be used for wharf, unloading yard, embankment revetment, wall, retaining wall, breakwater, diversion embankment, dock, gate, etc.; In temporary structures, can be used to seal the mountain, temporary shore expansion, cut-off, bridge cofferdam, large pipeline laying temporary ditch excavation retaining, water, sand, and so on; In flood fighting, it can be used for flood control, collapse prevention, sand and so on.

Hot Rolled steel sheet pile

Standard of our material

Applications of Z-shaped Sheet Piles

• Retaining walls
• Cofferdams
• Parking garages
• Environmental barrier walls
• Steel bulkhead walls
