Cold Rolled 304 Stainless Steel Sheet Coils 0.3 - 3.0mm SS Strip Rope
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | BA Stainless Steel Sheet Coils Strip,3.0mm Stainless Steel Sheet Strip,Stainless Steel 304 Sheet Strip |
||
Product Description
Cold Rolled 304 Stainless Steel Sheet & Coils Thickness 0.3 - 3.0mm SS Coil Stainless Strip Rope
| Product Name | Stainless steel sheet / plate |
| Technique | Cold Rolled / Hot Rolled |
| Grade(ASTM UNS) | 201 202 301 304 304L 321 316 316L 317L 347H 309S 310S 904L S32205 2507 254SMOS 32760 253MA N08926 etc. |
| Grade (EN) | 1.4301, 1.4307, 1.4541, 1.4401, 1.4404 ,1.4571, 1.4438, 1.4539, 1.4547, 1.4529, 1.4562, 1.4410, 1.4878, 1.4845, 1.4828, 1.4876, 2.4858, 2.4819 |
| Thickness | 0.1-300mm or as required |
| Width | 1000, 1219, 1500, 2000, 2500, 3000mm or as required |
| Length | 1000, 1500, 2438, 3000, 5800, 6000, 9000, 12000mm or as required |
| Standard | ASTM JIS AISI GB DIN EN |
| Surface Finished | BA, 2B, NO.1, NO.4, 4K, HL, 8K, Checkered |
| Certification | CE, ISO, SGS, BV |
| Edge | Mill Edge / Slit Edge |
| Quality | SGS Inspection |
| Main market | Asia/ Europe/ South America/ Africa/ North Americal |
| Delivery time | Within 5-10 Working Days |
| Port of Loading | Shanghai/ Tianjin/ Qingdao Port, China |
| Price Terms | CIF/ CFR/ FOB/ EX-WORK |
| Export Packing | Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package |
| Supply Ability | 5000 Tons per Month |
| Payment Terms | T/T L/C and Western Union etc. |
| Application | Building material,decorative,elevator,kitchenware etc. |
Size of our Stainless Steel Sheet in Stock
| Thickness | Width1000mm | Width 1219mm | Width 1500mm | Width 2000mm |
| 0.3mm | ★ | ★ | ||
| 0.4mm | ★ | ★ | ||
| 0.5mm | ★ | ★ | ||
| 0.6mm | ★ | ★ | ★ | |
| 0.8mm | ★ | ★ | ★ | |
| 1.0mm | ★ | ★ | ★ | |
| 1.2mm | ★ | ★ | ★ | |
| 1.5mm | ★ | ★ | ★ | |
| 2.0mm | ★ | ★ | ★ | ★ |
| 2.5mm | ★ | ★ | ★ | ★ |
| 3.0mm | ★ | ★ | ★ | ★ |
| 4.0mm | ★ | ★ | ||
| 5.0mm | ★ | ★ | ||
| 6.0mm | ★ | ★ | ||
| 8.0mm | ★ | ★ | ||
| 10.0mm | ★ | ★ | ||
| 12.0mm | ★ | ★ | ||
| 14.0mm | ★ | ★ | ||
| ≥16mm | ★ | ★ |
Stainless Steel 304 Stainless Steel Plate Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 304/L/H | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
Chemical Analysis of Ss 304 Stainless Steel Sheet
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 304 | min. max. |
- 0.08 |
- 2.0 |
- 0.75 |
- 0.045 |
- 0.030 |
18.0 20.0 |
- |
8.0 10.5 |
- 0.10 |
| 304H | min. max. |
0.04 0.10 |
- 2.0 |
- 0.75 |
-0.045 |
- 0.030 |
18.0 20.0 |
- |
8.0 10.5 |
|
SS UNS S30400 Cold Rolled Plates Mechanical Properties Table
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304H | 515 | 205 | 40 | 92 | 201 |
Equivalent Material of SS Werkstoff No 1.4301 Shim Sheet
| rade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 |
| 304H | S30409 | 304S51 | - | 1.4948 | X6CrNi18-11 | - | - |
Stainless Steel 304 Plate Dimensions Schedule
| Plate Surface finish | Thickness (mm) | Width (max mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed Sheet | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled Sheet | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
ASTM A240 SS 304 Plate Imperial Dimensions
| Plate Surface finish | Gauge (in) | Width (max in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished Sheet (not brushed) | 11–24 | 60 |
| Temper rolled Sheet Mexinox only | 13–29 | 48 |
Large Stock Of Stainless Steel 304 Sheet
|
|
