Monel K-500 Nickel Alloy Sheet Plate Hot Rolled Bright Anneal K500
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Monel k500 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Monel K500 |
|---|---|---|---|
| Thickness | 0.6 - 20.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | Monel K-500 Nickel Sheet Alloy,Hot Rolled Nickel Sheet Alloy,Anneal K500 Nickel Plate Alloy |
||
Product Description
Monel K-500 Nickel Alloy Sheet & Plate Hot Rolled Bright Anneal K500 Alloy Sheet
| Products Name | Monel K-500 Nickel Alloy Sheet & Plate |
| Thickness | Cold rolled: 0.6 - 3.0mm Hot rolled 4.0 - 30.0mm |
| Standard Size | 1000*2000mm 1219*2438mm 1219*3048mm 1500*6000mm |
| Surface | 2B NO.1 |
| MOQ | 50 kgs |
| Service | Laser Cutting, Surface Finishing |
| Packing | Waterproof paper and wooden pallets |
| Loading Port | Shanghai Port |
| Price term | FOB CFR CIF EXW |
| Payment term | 30% TT in advance , 70% TT balance against copy of B/L |
| Other Grade | Hastelloy C22 C4 X |
| Monel 400 K500 | |
| Incoloy 800 800H 800HT 825 925 | |
| Inconel 600 601 625 716 718 | |
| Stainless Steel Grade | 201 202 301 304L 309S 310S 316L 316Ti 317L 321 347 409L 410 410S 420J1 420J2 430 431 436L 439 440A/B/C 441 443 444 2205 2507 904L 254SMO 253MA |
MONEL K500 is a age-hardenable Nickel-Copper alloy which combines the corrosion resistance of Alloy 400 with high strength corrosion fatigue and erosion resistance.
MONEL K500 is a nickel-copper alloy, precipitation hardenable through additions of aluminum and titanium. MONEL K500 retains the excellent corrosion resistant characteristics of 400 and has enhanced strength and hardness after precipitation hardening when compared with 400. Alloy K500 has approximately three (3) times the yield strength and double the tensile strength when compared with 400. MONEL K500 can be further strengthened by cold working before the precipitation hardening.
Characteristics of Monel K-500 Nickel Alloy Plate
- Excellent mechanical properties from sub-zero temperatures up to about 480C.
- Corrosion resistance in an extensive range of marine and chemical environments. From pure water to non-oxidising mineral acids, salts and alkalis.
Applications of Monel K-500 Nickel Alloy Sheet
- Propeller and pump shafts.
- Pumps and valves used in the manufacture of perchlorethylene, chlorinated plastics.
Typical application for MONEL K500 which takes advantage of high strength and corrosion resistance are pump shafts, impellers, propeller shafts, valve components for ships and offshore drilling towers, bolting, oil well drill collars and instrumentation components for oil and gas production. It is particularly well suited for centrifugal pumps in the marine industry because of its high strength and low corrosion rates in high-velocity seawater.
MONEL K500 is non-magnetic. MONEL K500 should be annealed when welded and the weldment then stress relieved before aging.
High Performance Alloys, Inc. stocks Alloy K500 in a range of sizes including 3/8"-2-1/2" diameter cold drawn, annealed and aged, and 2-3/4"-10" diameter hot finished and aged. Material can be supplied in random lengths, cut to order or machined to your specifications. Machining includes drilling, turning, tapping, threading, CNC shapes, flanges and more.
Chemistry of Monel K-500 Nickel Alloy
Chemical Requirements |
|||||||
|---|---|---|---|---|---|---|---|
|
|
Ni |
Mn |
Si |
Fe |
Al |
S |
C |
|
Max |
|
1.50 |
0.50 |
2.00 |
3.15 |
0.010 |
0.18 |
|
Min |
63.00 |
|
|
|
2.30 |
|
|
Mechanical Property Requirements |
|||||
|---|---|---|---|---|---|
|
Ultimate Tensile |
Yield Strength (0.2% OS) |
Elong. |
Hardness Rockwell C, Min.
|
Hardness Brinell 3000 kg, min. |
|
| Cold Worked/SR Over 1(25.4) to 3 | |||||
| Min | 140 KSi | 100 KSi | 17.0 | 29 | 280 |
| Max | |||||
| Min | 965 MPa | 690 MPa | |||
| Max | |||||
| Hot Worked/ Aged Hardened | |||||
| Min | 140 KSi | 100 KSi | 20.0 | 27 | 265 |
| Max | |||||
| Min | 965 MPa | 690 MPa | |||
| Max | |||||
Standard Specifications of our Monel K500 Alloy Products
|
Form |
Standard |
|---|---|
|
Metal Type |
UNS N05500 |
|
Bar |
ASTM B865 QQ-N-286 |
|
Wire |
AMS4676 |
|
Sheet |
ASTM B865 QQ-N-286 |
|
Plate |
ASTM B865 QQ-N-286 |
|
Fitting |
|
|
Forging |
QQ-N-286 Din 17754 |
|
Weld Wire |
FM 60 ERNiCu-7 |
|
Weld Electrode
|
FM 190 ENiCu-7 Din 17753
|
|
Din |
2.4375 |
