Monel 400 Nickel Plate Alloy Sheet ASTM EN JIS 0.5 - 20.0mm Thickness
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Monel 400 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Monel 400 |
|---|---|---|---|
| Thickness | 0.6 - 20.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | Monel 400 Nickel Plate Alloy Sheet,20.0mm Nickel Plate Alloy Sheet,JIS Nickel Plate Sheet Alloy |
||
Product Description
Nickel Alloy 400 Monel 400 Sheet & Plate ASTM EN JIS GB Standard 0.5 - 20.0mm Thickness
| Products Name | Monel 400 Nickel Alloy Sheet & Plate |
| Thickness | Cold rolled: 0.6 - 3.0mm Hot rolled 4.0 - 30.0mm |
| Standard Size | 1000*2000mm 1219*2438mm 1219*3048mm 1500*6000mm |
| Surface | 2B NO.1 |
| MOQ | 50 kgs |
| Service | Laser Cutting, Surface Finishing |
| Packing | Waterproof paper and wooden pallets |
| Loading Port | Shanghai Port |
| Price term | FOB CFR CIF EXW |
| Payment term | 30% TT in advance , 70% TT balance against copy of B/L |
| Other Grade | Hastelloy C22 C4 X |
| Monel 400 K500 | |
| Incoloy 800 800H 800HT 825 925 | |
| Inconel 600 601 625 716 718 | |
| Stainless Steel Grade | 201 202 301 304L 309S 310S 316L 316Ti 317L 321 347 409L 410 410S 420J1 420J2 430 431 436L 439 440A/B/C 441 443 444 2205 2507 904L 254SMO 253MA |
Monel 400 alloy is a nickel copper alloy which has high strength over a wide temperature range up to 1000 F. It is regarded as being a ductile Nickel-Copper alloy with resistance to a wide variety of corrosive conditions. This alloy is most frequently applied in a range of environments going from mildly oxidizing through neutral and to moderately reducing conditions. Additional application area of this material is in marine environments and other non-oxidizing chloride solutions. Like with commercially pure Nickel, Monel 400 is low in strength in the annealed condition, for this reason a variety of tempers are used to achieve higher strength levels. Monel 400 is one of the few alloys that maintains its strength in sub-zero or cryogenic temperatures, so it is often used in those applications.
Application of Monel 400 Nickel Alloy Sheet
- Marine engineering
- chemical equipment
- hydrocarbon processing
- valves
- pumps
- fittings
- fasteners
- heat exchangers
- flexible metal hose
CHEMICAL COMPOSITION OF MONEL 400
| Element | Min | Max |
|---|---|---|
| Nickel + Cobalt | 63 | 70 |
| Manganese | 2.0 | 2.0 |
| Silicon | .50 | .50 |
| Cobalt | 1.00 | 1.00 |
| Iron | 2.5 | 2.5 |
| Sulfur | .024 | .024 |
| Carbon | .30 | .30 |
| Copper | Balance | Balance |
Equivalent Specifications
| Country | Body | Grade |
| USA | UNS | N04400 |
| France | AFNOR | NU30 |
| GB | BS | NA13 |
| Germany | DIN | 2.4360, 2.4361 |
ASTM Product Specifications
| Specification | Title |
| B163 |
Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes
|
| B366 |
Factory-Made Wrought Nickel and Nickel Alloy Fittings
|
| B564 |
Nickel Alloy Forgings
|
| B127 |
Nickel-Copper Alloy (UNS N04400) Plate, Sheet, and Strip
|
| B164 |
Nickel-Copper Alloy Rod, Bar, and Wire
|
| B165 |
Nickel-Copper Alloy (UNS N04400) Seamless Pipe and Tube
|
| B725 |
Welded Nickel (UNS N02200/UNS N02201) and Nickel Copper Alloy (UNS N04400) Pipe
|
| B730 |
Welded Nickel (UNS N02200/UNS N02201) and Nickel Copper Alloy (UNS N04400) Tube
|
