Hastelloy C276 Nickel Alloy Uns N10276 High Performance En 2.4819 1000mm 1219mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 0.6 - 3.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | Hastelloy C276 Nickel Alloy,En 2.4819 Nickel Sheet Alloy,Nickel Sheet Alloy 1219mm |
||
Product Description
HASTELLOY C276 UNS N10276 - High Performance Alloys EN 2.4819 Width 1000mm 1219mm
| Products Name | Hastelloy C276 Sheet & Plate |
| Thickness | Cold rolled: 0.6 - 3.0mm Hot rolled 4.0 - 30.0mm |
| Standard Size | 1000*2000mm 1219*2438mm 1219*3048mm 1500*6000mm |
| Surface | 2B NO.1 |
| MOQ | 50 kgs |
| Service | Laser Cutting, Surface Finishing |
| Packing | Waterproof paper and wooden pallets |
| Loading Port | Shanghai Port |
| Price term | FOB CFR CIF EXW |
| Payment term | 30% TT in advance , 70% TT balance against copy of B/L |
| Other Grade | Hastelloy C22 C4 X |
| Monel 400 K500 | |
| Incoloy 800 800H 800HT 825 925 | |
| Inconel 600 601 625 716 718 | |
| Stainless Steel Grade | 201 202 301 304L 309S 310S 316L 316Ti 317L 321 347 409L 410 410S 420J1 420J2 430 431 436L 439 440A/B/C 441 443 444 2205 2507 904L 254SMO 253MA |
HASTELLOY C276 is a Nickel-chromium-molybdenum wrought alloy that is considered the most versatile corrosion resistant alloy available. This alloy is resistant to the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in an as welded condition. Alloy C-276 also has excellent resistance to pitting, stress-corrosion cracking and oxidizing atmospheres up to 1900°F. Alloy C-276 has exceptional resistance to a wide variety of chemical environments.
Application of HASTELLOY C276
- Digesters and bleach plants in the paper industry.
- Components exposed to sour gas.
- Equipment for flue-gas desulfurisation plants.
- Evaporators, heat exchangers, filters and mixers used in sulfuric acid environments.
- Sulfuric acid reactors.
- Organic chloride process equipment.
- Equipment for processes utilizing halide or acid catalysts.
Chemical Composition of Hastelloy C276
|
Chemical Requirements |
|||||||
|---|---|---|---|---|---|---|---|
|
|
Ni |
Cr |
Mn |
Mo |
C |
Si |
Fe |
| Max % | Bal. | 16.5 | 1.0 | 17.0 | 0.010 | 0.08 | 7.0 |
| Min % | 14.5 | 15.0 | 4. | ||||
Standard Specification of Hastelloy C276 Material
| Form | Standard |
|
UNS |
UNS N10276 |
|---|---|
|
Bar |
ASTM B574 Din 17752 |
|
Wire |
|
|
Sheet |
ASTM B575 Din 17750 |
|
Plate |
ASTM B575 Din 17750 |
|
Fitting |
ASTM B366 |
|
Forging |
ASTM B564 |
|
Tube |
ASTM B619 ASTM B622 ASTM B626 Din 17751 |
|
Pipe |
ASTM B619 ASTM B622 ASTM B626 Din 17751 |
|
Weld Wire |
A5.14 ERNiCrMo-4 |
|
Weld Electrode |
A5.11 ENiCrMo-4 |
|
Din. |
2.4819 All Forms |
Our Service
- Laser Cutting: Processing width 2000mm Length 8000mm. Cutting thickness within 30mm
- Surface Finishing: 2B BA NO.4 HL 8K pvc film.etc
- Mark: Stamp the mark as clients request
- Packing: good packing suit for export
More Informations about the delivery
- Deliver time: 5 - 10 Days , based on the quantity
- Loading Port: Shanghai Port,China
- MOQ: 50 kgs
- Packing: waterproof paper or wooden box
