Custom Cutting Nickel Rod Alloy Forged Hastelloy C276 Bar 250mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Bars | Grade | Hastelloy C276 |
|---|---|---|---|
| Diameter | 6 - 250mm | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | Custom Cutting Nickel Rod Alloy,Nickel Rod Alloy C276 Bar,Nickel Rod Alloy Bar 250mm |
||
Product Description
Custom Cutting Forged Hastelloy C276 Alloy Rod Nickel Alloy C276 Bar & Rod Square Round Rod
| Form | Nickel Alloy Bars |
| Grade | Hastelloy C276, ASTM B574 UNS N10276, Nickel Alloy C-276 |
| Outer Diameter (mm) | 6mm-250mm or according to customer’s requirement |
| Length | 1meter, 3 meters and 6 meters or customer’s requirement |
| Standard | ASTM, ASME, EN, JIS, DIN, GB/T, etc |
| Process Method | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar & Rod |
| Surface Finish | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Other Grade |
Hastelloy : B2 B3 C22 C276 G30 X Incoloy: 800 800H 800HT 825 925 A286 330 Inconel: 600 601 617 625 718 725 X-750 Monel: 400 k-500 |
| Price Item | EXW FOB CFR CIF |
| Payment | 30% TT inadvance, 70% TT Balance against copy of B/L |
| Delivery Time | It depends on your bars order total quantity and stock of these mother origin materials. Usually from the start of the order to the completion of production is about 3-4 weeks |
| Quality Requirement | Mill test certificate will be offered with shipment, the third party inspection is available |
| Main Markets | Europe, North America, Middle East, Southeast Asia |
| Metal Test | High or low temperature impact test, metallographic analysis |
| Chemical Analysis | As nickel alloy C276 bars standard |
What is Hastelloy C276 round bar?
C276 Alloy Black Bar is an improved and wrought version of Hastelloy C. Which means that the Hastelloy 2.4819 Threaded Bar usually doesn’t need to be solution heat treated after being welded. Additionally, this improved Nickel Alloy C276 Polished Bar has vastly improved fabricability properties. . Hastelloy C276 B574 Hexagonal Bar has the ability to resist the formation of grain boundary precipitates in the heat affected welded area. Thus, this wrought nickel alloy 276 is considered to be well suited for applications in most chemical processes even when used in an as-welded condition.
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Hastelloy C276 Cold Drawn and Polish Bars | 3.00 - 75.00 | 1/8” - 3.00” | h8-h9-h10-h11 |
| Nickel Alloy C276 Cold Drawn and Ground Bars | 10.00 - 75.00 | 5/6” - 2.50” | h8-h9-h10-h11 |
| ASTM B574 UNS N10276 Peeled and Polished Bars | 40.00 - 150.00 | 1.50” - 6.00” | h11, ASTMA-484 h11-DIN 1013 |
| DIN 2.4819 Peeled and Ground Bars | 20.00 - 50.00 | 3/4″ - 2.00” | h9-h10-h11 |
| Hastelloy C276 Forged Bar | 150 - 355mm | 6.00"-14.00" |
Features of Hastelloy C276 Round Bar
- Precision Straightened Nickel Alloy C276 Bright Bars
- Highly controlled heat treatment with SCADA control
- Available in shape of Round, Hex, Flat, and Square
- Ultrasonic / Magnetic Particle Eddy current testing byn-circling , Rotating Prob
- Mirror Finish ASTM B574 UNS N10276 Bars
- Precision Tolerance
- Close Length Tolerance
- Unique Packaging of DIN 2.4819 Rod
- Alloy C276 Hex Bar is certified to all major international specs
Hastelloy C276 Round Bar Sizes
Standard lengths of 2000 to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 mm | 45.0 mm | 210.0mm |
| 6.0 mm | 50.0 mm | 220.0mm |
| 7.0 mm | 55.0 mm | 230.0mm |
| 8.0 mm | 60.0 mm | 240.0mm |
| 9.0 mm | 65.0 mm | 250.0mm |
| 10.0 mm | 70.0 mm | 300.0mm |
| 12.0 mm | 75.0 mm | 330.0mm |
| 16.0 mm | 80.0 mm | 350.0mm |
| 20.0 mm | 90.0 mm | 400.0mm |
| 25.0 mm | 100.0 mm | 420.0mm |
| 30.0 mm | 130.0 mm | 450.0mm |
| 35.0 mm | 160.0 mm | 480.0mm |
| 40.0 mm | 200.0 mm | 500.0mm |
Alloy C276 Round Bars Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | OR | EN |
|---|---|---|---|---|---|---|---|
| Hastelloy C276 | 2.4819 | N10276 | ХН65МВУ | - | NW 0276 | ЭП760 | NiMo16Cr15W |
2.4819 Hastelloy Rod and Bars Chemical Composition
| Grade | Ni | Mo | Cr | Fe | W | Co | Mn | C | v | P | S | Si |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hastelloy C276 | Bal | 15 – 17 | 14.5 – 16.5 | 4 – 7 | 3 – 4.5 | 2.5 max | 1.0 max | 0.01 max | 0.35 max | 0.04 max | 0.03 max | 0.08 max |
Hastelloy Alloy C276 Rods Mechanical & Physical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.89 g/cm33 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40% |
