Large Diameter Stainless Steel Pipe Grade 304 316L 310S 321 347 904L 2205 2507 254SMO
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Welded Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | Random Length Of 6m |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | 304 Stainless Steel Pipe |
||
Product Description
Large Diameter Stainless Steel Pipe Grade 304 316L 310S 321 347 904L 2205 2507 254SMO
| Product Name | Stainless steel pipe |
| Standard | ASTM AISI DIN,EN, GB JIS |
| Steel Grade | 200 Series: 201,202 300 Series: 301.304.304L,316,316L316Ti,317L.321.309s,310s 400 Series: 409L410,410s,420j1,420j2,430,444,441,436 Duplex Steel: 904L 2205,2507,21012520,2304 |
| Outer Diameter | 6-600mm(as required) |
| Thickness | 0.3mm-40mm (as required) |
| Length | 2000mm/2500mm/3000mm/6000mm/12000mm(as required) |
| Technique | Welded,Seamless |
| Surface | pickling / polished |
| Tolerance | 土1% |
| Price Terms | FOB.CFR.CIF |
Stainless Steel Pipe applies to petroleum, chemical industry, medical, power, boiler and other industry fields, with high temperature resistant, low temperature resistant, corrosion resistant.
Stainless Steel Pipe manufacturer Landee supplies Stainless Steel Pipes, SS Pipe, Stainless Steel Piping, SS piping for industrial segments.
Standard Specification of our Stainless Steel Pipe
Welded pipe
Welded stainless steel pipe is manufactured from 2B or HRAP stainless steel strip – formed (to shape) and longitudinally welded to completed pipe. With the exception of very large pipe welds are made without the addition of filler metal. Standard welded pipe is in nominal lengths of 6.0 to 6.1 metres.
Manufacturing specification:
- ASTM A312M – Austenitic
- ASTM A358M – Austenitic (large diameter)
- ASTM A790M – Duplex.
Seamless Pipe
Seamless stainless steel pipe is produced from hollow billets, which are then drawn across dies until they reach the final desired pipe size and wall thickness. Standard seamless pipe is in random lengths of 6.0 to 7.5 metres.
Manufacturing specification:
- ASTM A312M – Austenitic.
- ASTM A790M – Duplex
Stainless Steel Piping Systems
A stainless steel pipe system is the product of choice for carrying corrosive or sanitary fluids, slurries and gases, particularly where high pressures, high temperatures or corrosive environments are involved. As a result of the aesthetic properties of stainless steel, pipe is often use in architectural applications.
Stainless steel pipe can generally be defined as a heavy wall thickness tubing, with dimensions as specified by the American National Standards Institute (ANSI). Pipe dimensions are nominated by outside diameter indicated by the NPS (imperial) or DN (metric) designator and sometimes referred to as the ‘nominal bore’ – and wall thickness, is determined by the schedule number. The standard ASME B36.19 covers these dimensions.
Stainless steel pipe and fittings are supplied in the annealed condition to facilitate fabrication and ensure best corrosion resistance. Atlas Steels can also supply stainless steel pipe with an abrasive polished finish suitable for architectural applications.
