EN 1.4466 Stainless Steel Sheet Plate Thickness 0.5 - 20.0mm EN 10088
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 1.4466 |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | EN 20.0mm Stainless Steel Sheet Plate,EN 1.4466 Stainless Steel Sheet Plate,DIN Stainless Steel Sheet Plate |
||
Product Description
EN 1.4466 (X1CrNiMoN25-22-2) Stainless Steel Sheet Plate Thickness 0.5 - 20.0mm EN 10088
|
Product Type:
|
EN 1.4466 (X1CrNiMoN25-22-2) Stainless Steel Sheet Plate Thickness 0.5 - 20.0mm EN 10088 |
| Thickness | 0.4 - 30.0mm |
|
Standard
|
EN 10088-2 |
|
Width
|
1000mm,1219mm(4 feet),1250mm,1500mm,1524mm(5feet),1800mm,2200mmor as you required
|
|
Length
|
2000mm,2440mm(8 feet) 2500mm,3000mm,3048mm(10 feet),1800mm,2200mmor as you required
|
|
Surface
|
No.1,No.4,2B,BA,Hair Line,8K,Brush,Embossed and Mirror Finish or as your required.
|
| Other Grade | 201 202 304 304L 309S 310S 316L 317L 321 410 420 430 2205 2507 904l.etc and equal grade |
|
Packing
|
Standard export packing for stainless steel sheet:
1.surface polish, 2:bundle package, 3:wooden case,wooden pallet package, 4:container or bulk, 5:special according to customer's request |
|
Application
|
Stainless Steel Sheet are widely used in below fields:
1.Construction field,shipping building industry 2.Petroleum and Chemical Industries 3.Food and Mechanical Industries 4.Boiler Heat Exchange 5.Machinery and Hardware Industries |
1.4466, X1CrNiMoN25-22-2, AISI 310MoLN - specification and application
High-nickel austenitic stainless steel for parts and components of chemical apparatus used mainly in the production of urea. The grade is suitable for working at elevated temperatures. 1.4466 steel is used in the paper, nitrogen, pharmaceutical, petrochemical and cellulose industries.
Chemical composition % of the ladle analysis of grade 1.4466
| C(％) | Si(％) | Mn(％) | P(％) | S(％) | Cr(％) | Ni(％) | Mo(％) | N(%) |
| Max 0.020 | Max 0.70 | Max 2.00 | Max 0.025 | Max 0.010 | 24.00-26.00 | 21.00-23.00 | 2.00-2.50 | 0.10-0.16 |
MECHANICAL PROPERTIES ( FINAL HEAT TREATMENT OR Q/T) UNDER ROOM TEMPERATURE
- Condition: solution treatment
- Thickness/mm: 160
- σb/MPa: 540~740
- σ0.2≥/MPa: 250
- δ5≥(％): 40
- ψ≥(％): -
- Akv≥/J: 90
- Hardness HBS30: -
1.4466 shape and dimensions
| 1.4466 Round bar: | 1mm-800mm |
| 1.4466 Square bar: | 10mm * 10mm-600mm *600mm |
| 1.4466 Flat bar: | Thickness:8mm-800mm Width:10mm to 1500mm |
| 1.4466 Sheet or Plate: | Thickness:3mm-80mm Width:1.5mm to 1500mm |
| 1.4466 Strip or Coil: | Thickness:0.1mm-3mm Width:1.5mm-1500mm |
| 1.4466 Forgings: | Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes |
