DIN EN 1.4571 Stainless Steel Sheet Plate X6CrNiMoTi17-12-2 1000mm
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 1.4571 |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | ASTM HL Stainless Steel Sheet Plate,1.4571 Stainless Steel Sheet Plate,1000mm HL Stainless Steel Sheet Plate |
||
Product Description
DIN EN 1.4571 Material, X6CrNiMoTi17-12-2 Stainless Steel Sheet & Plate
|
Product Type:
|
1.4310 / X10CrNi18-8 Stainless Steel sheet,Stainless Steel plate
|
| Thickness | 0.4 - 30.0mm |
|
Standard
|
EN 10088-2 |
|
Width
|
1000mm,1219mm(4 feet),1250mm,1500mm,1524mm(5feet),1800mm,2200mmor as you required
|
|
Length
|
2000mm,2440mm(8 feet) 2500mm,3000mm,3048mm(10 feet),1800mm,2200mmor as you required
|
|
Surface
|
No.1,No.4,2B,BA,Hair Line,8K,Brush,Embossed and Mirror Finish or as your required.
|
|
Packing
|
Standard export packing for stainless steel sheet:
1.surface polish, 2:bundle package, 3:wooden case,wooden pallet package, 4:container or bulk, 5:special according to customer's request |
|
Application
|
Stainless Steel Sheet are widely used in below fields:
1.Construction field,shipping building industry 2.Petroleum and Chemical Industries 3.Food and Mechanical Industries 4.Boiler Heat Exchange 5.Machinery and Hardware Industries |
What are 1.4571 Stainless Steels?
1.4571 is the titanium version of 316 Stainless Steel. Stainless steel grade 1.4571 contains a minor percentage of titanium in its alloy composition. Titanium content is usually around 0.5%. The titanium atoms strengthen the structure of type 316 at temperatures above eight hundred degree centigrades. This helps to avoid carbide precipitation at the grain boundaries and eguards the material from the attack of corrosion. 1.4571 is also known as 316Ti. It can be held at elevated temperatures for an extended period. Most of the mechanical properties of 316 type remain same in 1.4571 grade.
Professionals know that 1.4571 has been used in the chemical processing industry for long even in the 1920s. 316L is appropriate for welding purposes of higher gauges whereas 1.4571 is appropriate for extensive application in the high-temperature environment. If 1.4571 intends to be welded, filler materials such as 1.4430, 1.4576 are recommended to be used.
Available Forms in Market
Following are the available forms of 1.4571 Stainless Steels:
- Plates
- Strips
- Forged Items
- Wire
- Tubing & pipes
- Bars
- L shape
- Rods
- Sheet
- Fittings
- Flanges
Chemical alloying compositions are explicated below
- Maximum percentage of Carbon is 0.08
- Maximum percentage of Manganese is 2.0
- Maximum percentage of Phosphorus is 0.05
- Maximum percentage of Sulphur is 0.03
- Percentage of Molybdenum is indicated between 2.0 to 2.5
- Maximum percentage of Silicon is 1.0
- Maximum percentage of Nickel is 13.5 and minimum is 10.5
- Maximum percentage of Titanium (Ti) is 0.70 and minimum is 0.40
- Maximum percentage of Chromium is 18.5 whereas the minimum percentage of Chromium is 16.5
Rest is the base metal i.e. iron.
1.4571 stainless steel have outstanding qualities even better than AISI 316 grade when it comes to withstanding high temperature for an extended period of time. This Type has other mechanical properties similar to 316 stainless steel except that it has titanium that makes it more stable for high temperature. It is also known as 316Ti material.
Mechanical Properties
- Tensile strength is in the range of 500-700 Mpa as in some sources.
- Yield strength is 200 Mpa (in some technical sources)
- Hardness in HB (in technical sources) is around 215.
- Minimum Elongation is 40% in 2″ in the standard.
- Density is 8.0 grams per cubic centimeters
- The melting point is around fourteen hundred degrees Celsius.
- This type can withstand temperature over 800 centigrades for the extended time period.
Equivalent Materials
The equivalent materials for 1.4571 Stainless Steels specified in other recognized standards are as follows:
- In JIS standard, the equivalent material is SUS 316Ti.
- In American standard, the equivalent material is 316Ti type steel.
- In UNS standard, the equivalent material is S31625 type steel.
- In UK standard, it is known as 320S31
Applications
Variety of industrial and household applications consume this material, some of the applications are as follows:
- Chemical and petrochemical equipment
- Food processing equipment
- Laboratory equipment
- Mining accessories
- Springs
- Bolts and Nuts
- Coastal paneling
- Heat Exchangers
- Medical devices
