EN 1.4310 Stainless Steel Sheet 1219mm X10CrNi18-8 Certificate 3.2
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 1.4310 |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | EN 1.4310 Stainless Steel Sheet,Stainless Steel Sheet 1219mm,Hairline Stainless Steel Sheet Plate |
||
Product Description
EN 1.4310 Stainless Steel Sheet X10CrNi18-8 Stainless Steel Certificate 3.2
|
Product Type:
|
1.4310 / X10CrNi18-8 Stainless Steel sheet,Stainless Steel plate
|
| Thickness | 0.4 - 30.0mm |
|
Standard
|
EN 10088-2 |
|
Width
|
1000mm,1219mm(4 feet),1250mm,1500mm,1524mm(5feet),1800mm,2200mmor as you required
|
|
Length
|
2000mm,2440mm(8 feet) 2500mm,3000mm,3048mm(10 feet),1800mm,2200mmor as you required
|
|
Surface
|
No.1,No.4,2B,BA,Hair Line,8K,Brush,Embossed and Mirror Finish or as your required.
|
|
Packing
|
Standard export packing for stainless steel sheet:
1.surface polish, 2:bundle package, 3:wooden case,wooden pallet package, 4:container or bulk, 5:special according to customer's request |
|
Application
|
Stainless Steel Sheet are widely used in below fields:
1.Construction field,shipping building industry 2.Petroleum and Chemical Industries 3.Food and Mechanical Industries 4.Boiler Heat Exchange 5.Machinery and Hardware Industries |
Material 1.4310 (X10CrNi18-8 steel) is a European standard austenitic stainless steel with good corrosion resistance and weldability, as well as high strength and ductility, it is widely used in the production of high strength stainless steel springs. DIN EN 1.4310 spring steel equivalent grades include AISI 301, JIS SUS301, GB 12Cr17Ni7.
DIN 1.4310 Stainless Steel Datasheet
The following tables summarize stainless steel 1.4310 datasheet and specification, including chemical composition, mechanical properties, physical properties and heat treatment.
Chemical Composition of 1.4310 Stainless Steel
The following table lists the material 1.4310 chemical composition based on the heat analysis.
| Chemical Composition % | ||||||||||
| Standard | Steel Grade (Steel Number) | C | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | Mo, ≤ | N, ≤ |
| EN 10088-2; EN 10088-3 |
X10CrNi18-8 (1.4310) | 0.05-0.15 | 2.00 | 2.00 | 0.045 | 0.015 | 16.0-19.0 | 6.0-9.5 | 0.80 | 0.10 |
Mechanical Properties of 1.4310 Stainless Steel
Datasheet 2: Material 1.4310 mechanical properties at room temperature in the solution-annealed condition and resistance to intergranular corrosion.
| Mechanical properties (Solution annealed) | |||||||||
| Country (Region) | Standard | Steel Grade (Steel Number) | Diameter (d) or Thickness (t) in mm | Hardness (HB), ≤ | 0.2% yield strength (MPa), ≥ | 1% yield strength (MPa), ≥ | Tensile strength (MPa) | Elongation (%) | Resistance to intergranular corrosion |
| European Union | EN 10088-3 | X10CrNi18-8 (1.4310) | ≤40 | 230 | 195 | 230 | 500-750 | 40 | No |
| Mechanical properties (Solution annealed) | |||||||||
| Country (Region) | Standard | Steel Grade (Steel Number) | Product Condition | Thickness (mm), ≤ | 0.2 % yield strength (Mpa), ≥, (Transverse) | 1 % yield strength (Mpa), ≥ (Transverse) | Tensile strength (MPa) | Elongation (%), ≥, (Transverse) | Resistance to intergranular corrosion |
| European Union | EN 10088-2 | X10CrNi18-8 (1.4310) | cold rolled strip | 8 | 250 | 280 | 600-950 | 40 | No |
| Yield strength at elevated temperatures | |||||
| Standard | Steel name (Material number) | Temperature, °C | 0.2% proof strength, MPa, ≥ | 1% proof strength, MPa, ≥ | Heat treatment condition |
| EN 10088-2; EN 10088-3 |
X10CrNi18-8 (1.4310) | 100 | 210 | 230 | Solution annealed |
| 150 | 200 | 215 | |||
| 200 | 190 | 205 | |||
| 250 | 185 | 200 | |||
| 300 | 180 | 195 | |||
| 350 | 180 | 195 | |||
Grade Specification
| EN X10CrNi18-8 (1.4310) material equivalent | |||||||||
| European Union | US | ISO | China | Japan | |||||
| Standard | Steel Name (Material Number) | Standard | Grade (UNS) | Standard | Grade (ISO number ) | Standard | Grade | Standard | Grade |
| EN 10088-2; EN 10088-3; EN 10088-1 |
X10CrNi18-8 (1.4310) | AISI; ASTM A240/A240M; ASTM A276/A276M; ASTM A959 |
AISI 301 (UNS S30100) | ISO 15510 | X10CrNi18-8 (4310-301-00-I ) | GB/T 1220; GB/T 3280 |
12Cr17Ni7; 1Cr17Ni7 (Old designation) |
JIS G4303; JIS G4304 |
SUS3 |
