OD 406mm Seamless Stainless Steel Pipe Welded SS316L EN 10204-3.1
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Welded Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | Random Length Of 6m |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | OD 406mm Stainless Steel Pipe,Seamless Stainless Steel Pipe Welded,EN 10204-3.1 Stainless Steel Pipe |
||
Product Description
Seamless Steel Pipe OD10 - OD406mm Custom SS316L Stainless Steel Pipe According to EN 10204-3.1
Stainless steel TP 316L seamless pipes in the market have got greater popularity among the industrialists because of its high quality of production. In the manufacturing industry the product is created by using good quality of raw materials, latest technology, and modern tools complying with raw material standard quality. MBM tubes Pvt. Ltd. a reliable industry is focuses on the demands of customers and they are offering the product in wide comprehensive range so that all application wants can be fulfilled effectively.
The product is having several good features to offer:
• Weld-ability
• Durability
• Resistivity
• Good dimensional accuracy
• Rugged construction
• High tensile strength
Specifications-
• Size- The size in which product is available is 6NB to 1200NB.
• Outer Diameter- The OD of seamless pipes is 1/8” NPS to 12” NPS.
• Wall thickness-The wall thickness of the product is 0.6mm to 12.7mm.
• Schedules- Its schedule is SCH 5, 20, 10, 40, 60, 140, 120, 160, XXS.
• Standards- The standards of the product are ASTM SA 312/ ASTM A 321.
• Length- The length in which product available is double/single random and in cut length.
• Types- The types in which product available are like honed, rectangle, square, round, hydraulic.
• Ends- The ends of products provided are the plain and beveled end.
Testing-
The testing in a reliable industry is conducted so that the quality of the product can be assured to be good like-
• Hardness test.
• Pitting resistance test.
• Hydrostatic/radiography test.
• Chemical/mechanical test.
• Micro/macro test.
• IGC/PMI test.
Pipe Specification
- Range : 6NB to 1200NB
- Outer Diameter : 1/8" NPS to 12" NPS
- Thickness : 0.6 mm to 12.7 mm
- Schedules : SCH. 5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XXS.
- Length : Single Random, Double Random & Cut Length
- Specifications : ASTM A312 / ASTM SA312
- Types : Round, Square, Rectangle, Hydraulic, Honed Tubes
- End : Plain End, Beveled End
| STANDARD | UNS | WERKSTOFF NR. | JIS | AFNOR | BS | GOST | EN |
| SS 316L | S31603 | 1.4404 / 1.4435 | SUS 316L | Z3CND17‐11‐02 / Z3CND18‐14‐03 | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
MBM Pipe Pvt. Ltd. is Manufacturer & Exporter of Stainless Steel 316L Seamless Pipes in Dahej, Ankleshwar, Thane, Bengaluru, Pune, Hyderabad.
Chemical Composition
|
|
|
| Ni | 10 - 14 |
| N | 0.10 max |
| Cr | 16 – 18 |
| C | 0.08 max |
| Si | 0.75 max |
| Mn | 2 max |
| P | 0.045 max |
| S | 0.030 max |
| Mo | 2.00 - 3.00 |
Mechanical Properties
| Grade | 316L |
| Tensile Strength (MPa) min | 485 |
| Yield Strength 0.2% Proof (MPa) min | 170 |
| Elongation (% in 50mm) min | 40 |
| Hardness | |
| Rockwell B (HR B) max | 95 |
| Brinell (HB) max | 217 |
Grade Specifications
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 316L | S31603 | S31603 | - | 1.4404 | X5CrNiMo17-12-2 | 2348 | SUS 316L |
Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 316L | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
