SS316L Seamless Stainless Steel Hollow Tube Pipe ASTM EN DIN JIS 40mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Welded Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | Random Length Of 6m |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | Seamless Stainless Steel Hollow Tube,SS316L Stainless Steel Hollow Tube,JIS 40mm Stainless Steel Hollow Tube |
||
Product Description
SS316L Stainless Steel Pipe ASTM EN DIN JIS GB Standard Seamless Stainless Steel Hollow Tube
| Product Name | Stainless steel pipe |
| Standard | ASTM AISI DIN,EN, GB JIS |
| Steel Grade | 200 Series: 201,202 300 Series: 301.304.304L,316,316L316Ti,317L.321.309s,310s 400 Series: 409L410,410s,420j1,420j2,430,444,441,436 Duplex Steel: 904L2205,2507,21012520,2304 |
| Outer Diameter | 6-600mm(as required) |
| Thickness | 0.3mm-40mm (as required) |
| Length | 2000mm/2500mm/3000mm/6000mm/12000mm(as required) |
| Technique | Welded,Seamless |
| Surface | pickling / polished |
| Tolerance | 土1% |
| Price Terms | FOB.CFR.CIF |
STOCK SIZE RANGE AND SPECIFICATIONS:
WELDED PRODUCT |
SEAMLESS PRODUCT |
|
NPS: 1/8” through 24”
|
NPS: 1/8” through 8”
|
|
Schedules: 5, 10S, 10, 30, 40S, 40, 80, 80S
|
Schedules: 10, 40, 80, 160, XXH
|
| Specifications: ASTM A312, ASME SA312 | Specifications: ASTM A312,ASME SA312 |
316 / 316L STAINLESS STEEL PIPE
These grades of austenitic stainless steels are similar to 304 and 304L, but with the addition of molybdenum. The addition of molybdenum improves the alloys corrosion resistance, particularly with higher resistance to pitting and crevice corrosion in chloride environments. The austenitic structure allows excellent toughness, even down to cryogenic temperatures. These grades have excellent weld-ability, with or without the addition of filler metal.
Corrosion tested to MIL-P-24691/3 or A262 Practice E
| Weight % | C | Mn | P | S | Si | Cr | Ni | Mo |
|---|---|---|---|---|---|---|---|---|
| 316 | .08 | 2.00 | .045 | .030 | 1.00 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
| 316L | .035 | 2.00 | .045 | .030 | 1.00 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Grade | Tensile | ||||
|---|---|---|---|---|---|
| Ultimate/Min | Yield/Min | Elongation/Min | |||
| KSI | MPA | KSI | MPA | % | |
| 316 | 75 | 515 | 30 | 205 | 35 |
| 316L | 70 | 485 | 25 | 170 | 35 |
