Heat Resistant 310S Stainless Steel Pipe Tube EN 1.4845 Stainless Steel Tubing SS Pipe Schedul 40 Schedul 80
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Welded Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | Random Length Of 6m |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | EN 1.4845 Stainless Steel Pipe,Heat Resistant Stainless Steel Pipe,Schedul 80 Stainless Steel Pipe |
||
Product Description
Heat Resistant 310S Stainless Steel Pipe Tube EN 1.4845 Stainless Steel Tubing SS Pipe Schedul 40 Schedul 80
310S is a heat-resistant stainless steel mainly used in high-temperature environments. It is a type of austenitic stainless steel that contains especially large amounts of chromium and nickel.
It has higher corrosion resistance than SUS304, the most widely circulated stainless steel, and better heat resistance than SUS309S, a heat-resistant stainless steel.
However, its workability is inferior to SUS304 and SUS309S. Furthermore, because it contains a large amount of relatively expensive nickel, its price is approximately three to four times that of SUS304.
Another characteristic of SUS310S is that it is not magnetic. Austenitic steels are inherently not magnetic, but some grades can become magnetic when cold worked. However, because of its high nickel content, SUS310S does not become magnetic even when processed.
| Material | 310S Stainless Steel Pipe |
| Wall Thickness | 1.0 - 40.0mm or other thickness as request |
| Outer Diameter | 10 - 406mm |
| Length | 5 - 8m or custom cutting any length as request |
| Packing | Bundle, or with all kinds of colors PVC or as your requirements |
| Product Application | Oil, offshore oil, chemical industry, medical machinery, aerospace, nuclear power, shipbuilding, high pressure boiler, heat exchanger, pressure vessel, condenser, water conservancy, electricity and other industries |
| Delivery Detail | Inventory About 3-5 days； custom-made 10-15 days；riding to order's quantity. |
| Packing | Standard export packing |
| Payment Terms | L/C T/T (30%DEPOSIT) |
Typical Analysis of 310S Stainless Steel Pipe
| 310S | Cr% | Ni% | C% | Si% | Mn% | P% | S% | Mo% | Cu% | Fe% |
| MIN | 24.0 | 19.0 | - | - | - | - | - | - | - | - |
| MAX | 26.0 | 22.0 | 0.08 | 0.75 | 2.0 | 0.045 | 0.03 | 0.75 | 0.5 | Bal |
Mechanical Properties of 310S Stainless Steel Pipe
The properties quoted below are guideline figures only and should not be used for any design purposes
| Temperature ºC | 100 | 500 | 800 | 1000 | 1100 |
| UTS (Nmm²) | 600 | 475 | 215 | 85 | 45 |
| 0.2% (Nmm²) | 265 | 175 | 110 | ||
| Elongation % | 41 | 35 | 30 | 54 | 57 |
Marking On ASTM A312 TP 310 Seamless Pipe
All material will be marked as follow:
- Material grade
- Heat Number
- Size
- Manufacturer’s name
SS 310 Seamless Pipe Weight Chart
We are alloy 310 Welded Pipe Suppliers, Call for Material test certificate and sample of astm a 213 tp 310 tube, ASME SA 312 TP 310 ERW Pipe, Check ss 310 seamless pipe Weight Chart
| Nominal size [inches] | Outside diameter [inches] | Outside diameter [mm] | Wall thickness [inches] | Wall thickness [mm] | Weight [lb/ft] | Weight [kg/m] |
| 1/8 | 0.405 | 10.3 | 0.095 | 2.41 | 0.31 | 0.47 |
| 1/4 | 0.54 | 13.7 | 0.119 | 3.02 | 0.54 | 0.8 |
| 1/2 | 0.84 | 21.3 | 0.147 | 3.73 | 1.09 | 1.62 |
| 3/4 | 1.05 | 26.7 | 0.154 | 3.91 | 1.47 | 2.2 |
| 1 | 1.315 | 33.4 | 0.179 | 4.55 | 2.17 | 3.24 |
| 1 1/4 | 1.66 | 42.2 | 0.191 | 4.85 | 3 | 4.47 |
| 1 1/2 | 1.9 | 48.3 | 0.2 | 5.08 | 3.63 | 5.41 |
| 2 | 2.375 | 60.3 | 0.218 | 5.54 | 5.02 | 7.48 |
| 2 1/2 | 2.875 | 73 | 0.276 | 7.01 | 7.66 | 11.41 |
| 3 | 3.5 | 88.9 | 0.3 | 7.62 | 10.25 | 15.27 |
| 3 1/2 | 4 | 101.6 | 0.318 | 8.08 | 12.5 | 18.63 |
| 4 | 4.5 | 114.3 | 0.337 | 8.56 | 14.98 | 22.32 |
| 5 | 5.563 | 141.3 | 0.375 | 9.53 | 20.78 | 30.97 |
| 6 | 6.625 | 168.3 | 0.432 | 10.97 | 28.57 | 42.56 |
| 8 | 8.625 | 219.1 | 0.5 | 12.7 | 43.39 | 64.64 |
| 10 | 10.75 | 273 | 0.594 | 15.09 | 64.43 | 96.01 |
| 12 | 12.75 | 323.8 | 0.688 | 17.48 | 88.63 | 132.08 |
| 14 | 14 | 355.6 | 0.75 | 19.05 | 106.13 | 158.1 |
| 16 | 16 | 406.4 | 0.844 | 21.44 | 136.61 | 203.53 |
| 18 | 18 | 457 | 0.938 | 23.83 | 170.92 | 254.55 |
| 20 | 20 | 508 | 1.031 | 26.19 | 208.87 | 311.17 |
| 24 | 24 | 610 | 1.125 | 30.96 | 296.58 | 442.08 |
