Cold Rolled Stainless Steel Sheet 1500mm 1800mm 304 0.6 - 8.0mm From TISCO
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 201 304 430 316L |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | waterproof paper and wooden pallets packing |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Material | Stainless Steel Sheet |
|---|---|---|---|
| Grade | 201 304 430 316L | Standard | EN 10088-2 |
| Thickness | 0.4 - 100mm | Width | 1000mm 1219mm 1500mm 2000mm |
| Surface | 2B NO.1 | Service | Cutting, Surface Finishing |
| Highlight | TISCO Stainless Steel Sheet,1500mm Stainless Steel Sheet,0.6mm 304 Stainless Steel Sheet |
||
Product Description
Cold Rolled 1500mm 1800mm 2000mm Width 304 Stainless Steel Sheet Thickness 0.6 - 8.0mm from TISCO
Stainless steel 304 sheet/plate 304 is regularly used for aerospace, food and beverage, machinery, architectural, chemical, and cryogenic applications. 304 stainless is the most common stainless-steel alloy on earth. With the exception of marine and other highly corrosive environments, it provides high strength and good corrosion resistance. Stainless steel 304 plate stock is available in a wide range of dimensions, including standard and custom-cut lengths. Easily price and order online today and enjoy the convenience of having your purchase shipped directly to you.
We carry stainless 304 sheet/plate in Annealed 2B Finish, Annealed No. 4(Brushed) Finish, Annealed No. 8(Mirror) Finish, and Precision Ground.
| Material | Stainless Steel Sheet |
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Steel Grade | 200 Series: 201,202 300 Series: 301,304,304L,316,316L,316Ti,309,310,317,321 400 Series: 409,410,420,430,436,444,441,440c Duplex Steel: 904L,2205,2507,2101,2520,2304 |
| Thickness | Thin Sheet: 0.1mm-3mm Thick Plate: 3mm-16mm Extra Thick Plate: 16mm-115mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm |
| Length | 2000mm, 2438mm, 3000mm, 3500mm, 4000mm, 6000mm |
| Manufacturing Method | Cold Rolled, Hot Rolled |
| Edges | Mill Edges, Silt Edges |
| Surface | No.1, 2D, 2B, BA, 8K, No.4, Hairline, Sandblasting |
| Surface Treatment | Corrugated, Perforated, Embossed, Etched, Water Rippled |
| Color | Golden, Champagne gold, Rose gold, Brown, Bronze, Brass, Black, etc. |
| Delivery Time | In stock: 5-10 days, Not in stock: 10-20 days |
| Payment Terms | T/T, L/C, Paypal, Credit Card, Trade Online |
| MOQ | 1 Ton |
Chemical Analysis of Ss 304 Sheet
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 304 | min. max. |
- 0.08 |
- 2.0 |
- 0.75 |
- 0.045 |
- 0.030 |
18.0 20.0 |
- |
8.0 10.5 |
- 0.10 |
| 304H | min. max. |
0.04 0.10 |
- 2.0 |
- 0.75 |
-0.045 |
- 0.030 |
18.0 20.0 |
- |
8.0 10.5 |
|
SS UNS S30400 Cold Rolled Plates Mechanical Properties Table
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304H | 515 | 205 | 40 | 92 | 201 |
| 304H also has a requirement for a grain size of ASTM No 7 or coarser. | |||||
Equivalent Material of SS Werkstoff No 1.4301 Shim Sheet
| rade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 |
| 304H | S30409 | 304S51 | - | 1.4948 | X6CrNi18-11 | - | - |
Stainless Steel Sheet 304 Applications:
- Food preparation equipment, especially in chloride environments
- Chemical processing, equipment
- Laboratory benches and equipment
- Rubber, plastics, pulp & paper machinery
- Pollution control equipment
- Boat fittings, value and pump trim
Stock Informations of our cold rolled 304 stainless steel sheets
| Thickness | 1500mm width | 1800mm width | 2000mm width |
| 0.6mm | ★ | ||
| 0.8mm | ★ | ||
| 1.0mm | ★ | ||
| 1.2mm | ★ | ||
| 1.5mm | ★ | ||
| 2.0mm | ★ | ★ | ★ |
| 2.5mm | ★ | ★ | ★ |
| 3.0mm | ★ | ★ | ★ |
| 4.0mm | ★ | ★ | ★ |
| 5.0mm | ★ | ★ | ★ |
| 6.0mm | ★ | ★ | ★ |
| 8.0mm | ★ | ★ | ★ |
Chemical Composition of 304 Stainless Steel
Type 304 grade stainless steel composition is given in table below.
Datasheet 1, AISI 304 stainless steel composition
| Chemical Composition, % | ||||||||||
| ASTM | AISI (UNS) | C, ≤ | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | N, ≤ | Product |
| ASTM A240/A240M | 304 (UNS S30400) | 0.07 | 0.75 | 2.00 | 0.045 | 0.030 | 17.5-19.5 | 8.0-10.5 | 0.10 | Plate, Sheet, and Strip |
| ASTM A276/276M | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-11.0 | – | Bars and Shapes | |
SS304 Stainless Steel Mechanical Properties
Datasheet-2, the tables below list SS304 material mechanical properties including yield strength, tensile strength, elongation and hardness, etc.
| Mechanical Properties, data are for 25.4 mm (1 in.) diameter bar | ||||||
| Steel (UNS) | Tensile strength, MPa (ksi) | Yield strength, MPa (ksi) | Elongation in 50 mm (2 in.), % ≥ | Reduction in area (%) | Hardness (HB) | Condition |
| AISI 304 (UNS S30400) | 585 (85) | 235 (34) | 60 | 70 | 149 | Annealed bar |
| 690 (100) | 415 (60) | 45 | 212 | Annealed and cold drawn | ||
| 860 (125) | 655 (95) | 25 | 275 | Cold drawn high tensile | ||
