SCH40 904L Cutting Stainless Steel Pipe Tube SCH80 SCH160 SS Seamless
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L 321 310S 314 2205 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | Random Length Of 6m |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting |
| Highlight | SCH40 904L Stainless Steel Pipe,Seamless cutting Stainless Steel Pipe,Seamless Stainless Steel Pipe SCH160 |
||
Product Description
904L Stainless Steel Pipe & Tube SCH40 SCH80 SCH160 SS Pipe Seamless Steel Pipe
| Products | TP904L Stainless Steel Pipe |
| Type | Seamless Pipe |
| Grade | 304 304L 309S 310S 316L 321 317L 316Ti 2205 2507 904L |
| Out Diameter | OD10 - 406mm |
| Length | 6m or custom cutting any length as request |
| Thickness | SCH10 SCH40 SCH80 SCH160 or unstandard size |
| Loading Port | Shanghai Port |
| MOQ | 500 kgs |
| Packing | standard Packing suit for export |
UNS NO8904, commonly known as 904L, is a low carbon high alloy austenitic stainless steel which is widely used in applications where the corrosion properties of AISI 316L and AISI 317L are not adequate.
The addition of copper to this grade gives it corrosion resistant properties superior to the conventional chrome nickel stainless steels, in particular to sulphuric, phosphoric and acetic acids. However, there is limited use with hydrochloric acids. It also has a high resistance to pitting in chloride solutions, a high resistance to both crevice and stress corrosion cracking. Alloy 904L performs better than other austenitic stainless steels due to the higher alloying of nickel and molybdenum.
The grade is non-magnetic in all conditions and has excellent formability and weldability. The austenitic structure also gives this grade excellent toughness, even down to cryogenic temperatures.
The high chromium content promotes and maintains a passive film which protects the material in many corrosive environments.904L has a greater resistance to precipitation of ferrite and sigma phases on cooling and welding than other stainless steels containing molybdenum such as 316L and 317L. There is no risk of intercrystalline corrosion on cooling or welding due to the low carbon content. Its maximum service temperature is at 450°C.
This grade is particularly useful in control and instrumentation tubing applications where 316 and 317L are not suitable.
Available tube product forms
- Straight
- Coiled
- Seamless
Typical Applications
- Seawater cooling equipment
- Chemical processing for sulphuric, phosphoric and acetic acids
- Gas washing
- Condenser tubes
- Control and instrumentation
- Heat exchangers
Typical manufacturing specifications
- ASTM A213
- ASTM A269
- ASTM A312
- BS EN 10216 pt.5
- Also individual customer specifications.
Industries predominantly using this grade
- Chemical processing
- Oil and gas
- Pharmaceutical
Technical Data
Mechanical Properties
| Temper | Annealed | |
|---|---|---|
| Tensile Rm | 71 | ksi (min) |
| Tensile Rm | 490 | MPa (min) |
| R.p. 0.2% Yield | 32 | ksi (min) |
| R.p. 0.2% Yield | 220 | MPa (min) |
| Elongation (2” or 4D gl) | 35 | % (min) |
Physical Properties (Room Temperature)
| Specific Heat (0-100°C) | 450 | J.kg-1.°K-1 |
| Thermal Conductivity | 11.5 | W.m -1.°K-1 |
| Thermal Expansion | 15.8 | μm/μm/°C |
| Modulus Elasticity | 190 | GPa |
| Electrical Resistivity | 9.52 | μohm/cm |
| Density | 7.95 | g/cm3 |
Chemical Composition (% by weight)
| Element | Min | Max |
|---|---|---|
| C | - | 0.02 |
| Mn | - | 2 |
| Ni | 23 | 28 |
| Cr | 19 | 23 |
| S | - | 0.3 |
| Mo | 4 | 5 |
| N | - | 0.1 |
| Cu | 1 | 2 |
| P | - | 0.03 |
| Si | - | 0.7 |
