ASTM A276 416 Stainless Steel Round Bar Hot Rolled 8 - 350mm Custom Cutting
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 309S 310S 2205 17-4PH XM-19 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 309S 310S 321 329 416 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | Stainless Steel Round Bar 350mm,A276 416 Stainless Steel Round Bar,Hot Rolled Stainless Steel Bar |
||
Product Description
ASTM A276 416 Stainless Steel Round Bar Hot Rolled Diameter 8 - 350mm Custom Cutting
| Products | Stainless Steel Bar |
| Grade | 416 |
| Diameter | 4 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or cutting as request |
416 stainless steel is a magnetic martensitic stainless grade that is known for free machining. It has the largest machinability of all stainless steel grades. 416 stainless steel as well as similiar grades are not as resistant to corrosion as other stainless types, it establishes moderate corrosion with high strength on tempered and hardened conditions.
Chemical Properties:
| C | Mn | Si | P | S | Cr | |
|---|---|---|---|---|---|---|
| 416 | 0.15 max |
1.25 max |
1.00 max |
0.06 max |
0.15 max |
min: 12.0 max: 14.0 |
Mechanical Properties:
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) |
Elongation (% in 50mm) |
Hardness Brinell (HB) |
Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 517 | 276 | 30 | 262 | – |
| Condition T ** | 758 | 586 | 18 | 248-302 | – |
| 204 | 1340 | 1050 | 11 | 388 | 20 |
| 316 | 1350 | 1060 | 12 | 388 | 22 |
| 427 | 1405 | 1110 | 11 | 401 | # |
| 538 | 1000 | 795 | 13 | 321 | # |
| 593 | 840 | 705 | 19 | 248 | 27 |
| 650 | 750 | 575 | 20 | 223 | 38 |
| * Annealed properties are typical for Condition A of ASTM A582. | |||||
| ** Hardened and tempered Condition T of ASTM A582 – Brinell Hardness is specified range, other properties are typical only. | |||||
| # Due to associated low impact resistance this steel should not be tempered in the range 400- | |||||
Resistance
Resistant to food/water produce, and atmospheric conditions. While 416 stainless steels are not ideal for sulfuric chemical environments such as oceanic settings. Resistant to heat below its treatment temperature.
Processing
Commonly heat-treated at ~1400°F. This grade can be treated to achieve different mechanical properties, but it lacks high corrosion resistance. The ability to heat treat the grade allows it to be viable in many applications. Our 416 stainless steel can come in two conditions including condition Annealed and condition T.
Physical Properties:
|
Condition
|
Tensile | Yield | Enlongation | Reduction of Area |
Hardness |
| Annealed | 70 | 40 | 30 | - | 262 |
| T | 110 | 85 | 18 | - | 248-302 |
Applications
- Pump Shafts
- Bolts
- Valves
- Screws
- Gears
- Fasteners
- Studs
- Motor Shafts
Benefits
- Corrosion resistance to natural food acids, natural waters, and waste products
- Known for being the free machining grade
- Its hardenability allows it to be used in various applications
- Fair resistance to sealing at mild temperatures
