EN 1.4542 Stainless Steel Bar Rod EN 10088-3 Black SS Diameter 4 - 350mm Polishing
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 309S 310S 2205 17-4PH |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 309S 310S 321 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | EN 1.4542 Stainless Steel Bar,4mm Stainless Steel Bar Rod,Polishing Surface Stainless Steel Bar Rod |
||
Product Description
EN 1.4542 Stainless Steel Bar EN 10088-3 Stainless Rod Black SS Rod Diameter 4 - 350mm
| Products | Stainless Steel Bar |
| Grade | 17-4PH / 630 / UNS S17400 / 1.4542 |
| Diameter | 4 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or cutting as request |
Description
Alloy 1.4542 is a structurally hardened martensitic stainless steel which combines a hardness of about 48 HRC with good corrosion resistance.
This grade has a hardening peak at 480°C which allows easy ageing after machining on an initially solution treated condition. The grade is remelted to improve the cleanliness and homogeneity of the material.
Stainless has a number of sources in stock, as well as different formats or states of the product to suit your processing needs.
This product can also be custom made or cut into slugs by our service centres.
Main applications
Due to its good resistance to corrosion, its good hardness in the treated state (48HRC) and its resilience, the grade is used in particular in the manufacture of instruments for the medical sector (drills, etc.), in general mechanics, in the food industry and in the automotive sector.
Metallurgy
The manufacturing processes associated with the transformation processes make it possible to obtain a homogeneous microstructure. In the treated state, the microstructure consists of martensite and nanometric intermetallic precipitates (Ni3Cu) which germinate during ageing.
Machinability
Forgeability
The grade can be hot forged in the 900/1250°C temperature range. Resolving will be necessary to achieve maximum hardness.
Weldability
The grade can be welded using most processes. Welding should preferably be done before ageing to avoid embrittlement of the heat affected zone.
Typical heat treatments
Corrosion resistance
The grade has very good corrosion resistance but must be passivated. The microstructure contains little or no chromium carbides, which makes it less susceptible to intergranular corrosion.
Standard Sizes
Round or flat bars annealed (Condition A or AT) or pre-treated. Surface ground or peeled depending on diameter
Flat bars made to measure in the annealed condition (consult us)
Other format : sheets
Standards and designations
Numerical designations:
W. Nr 1.4542 – AISI 630 – UNS S17400
Standards:
NF S 94-090 – ASTM F 899 – NF EN 10088-3 – ISO 7153-1 -ASTM A564
X5CrNiCuNb16-4 – AFNOR Z6CNU17-04
Chemical composition
C<0.07
Mn<1.0
P<0.040
S<0.030
Si<1.0
15.0<Cr<17.50
3.0<Ni<5.0
3.0<Cu<5.0
0.15<Nb+Ta<0.45
Co<0.10
