EN 1.4404 Flat Stainless Steel Bar EN 1.4301 20x3mm-200x20mm Hot Rolled Annealed
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 2205 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Flat | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 310S 321 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | 10*3-200*20mm |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | Flat Stainless Steel Bar,EN 1.4404 Stainless Steel Bar,Hot Rolled stainless steel flat bar |
||
Product Description
EN 1.4301 EN 1.4404 Stainless Steel Flat Bar 20*3mm - 200*20mm SS Flat Bar Hot Rolled Annealed
Products Specification of our stainless stainless flat bar
| Products | Stainless Steel Flat Bar |
| Size | 20*3mm - 200*20mm |
| Length | 6m or as request |
| Tech | hot rolled / cold rolled |
| Main Grade | 201 304 304L 309S 310S 316L 316Ti 410 420 430 2205 2507 904L.etc |
| Standard | ASTN JIS GB EN |
| Service | cutting, surface finishing |
| MOQ | 500 kgs |
Stainless steel alloys are very common as they are used across all industries. From being made into fasteners to their use in machinery, the Stainless Steel Flat Bar can connect the dots to several requirements. The most popular alloys under the stainless steel category belong to the 300 series. Austenitic in terms of their classification, the 300 series Stainless Steel Flat Trim Strips have a face-centered cubic crystalline microstructure. This microstrure indicates that the atoms present in the Stainless Steel Flat Strip are packed in a very close knit fashion. Hence, the closely packed atomic arrangement affects the ductility, which in the case of 300 series alloys tends to be higher. The most popular and economical grade that is found in multiple projects is grade 304 Stainless Steel Flat Bar. The alloy has moderate strength and good resistance to some types of corrosion. Because the material is inexpensive in comparison to several stainless steel alloys, they are favored by all Stainless Steel Flat Bar Supplier across the world.
On the heels of grade 304 is alloy 316, which is also an austenitic grade. Yet the difference between them both is the addition of molybdenum in the alloy of 316 Stainless Steel Flat Bar. This molybdenum grade has tensile properties that are more enhanced than the former. While the properties of grade 304 are good enough, and the price is very economical, it is very difficult to machine this stainless steel. As a means to improve the machinability of this alloy, 303 Stainless Steel Flat Bar or as referred to as machine free grade was introduced into the market. Along with having lower corrosion resistance properties, the toughness of grade 303 Stainless Steel Flat Stock is lower than 304.
pecification Chart of Stainless Steel Flat Bar
| Grade | All Stainless Steel Grades |
|---|---|
| Bar Finishing | Polish & Bright, Flat |
| Other Services | Centreless Grinding (CG), Machining (CNC), Anneling, Heat Treatment, Polish, Pickling, Forging, Rolling, Cutting, Minor Fabrication, Bending, |
| Test Certificate | Manufacturer and Laboratory Test Certificate from Govternment Approved Lab / Under third Party Inspection & witd Excise Gate Pass to avail Modvat benefit. |
Equivalent of 304 Stainless Steel Flat Bar
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18-09 | X5CrNi18-10 |
| SS 304L | 1.4306/1.4307 | S30403 | SUS 304L | 304S11 | 03Х18Н11 | Z7CN18‐09 | X2CrNi18-9 / X2CrNi19-11 |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | - | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Ss 304 Flat Bar Processing
- Stainless Steel Flat Bar Cutting
- Stainless Steel 316 Flat Bar Heat Treating
- Stainless Steel 304 Flat Bar Machining
- SS Flat Bar Additional Services
Stainless Steel 316 Flat Bar Sizes
| Metric Stainless Steel Flat bar | 6mm, 8mm, 10mm , 12mm, 13mm, 14mm, 15mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 120mm, 150mm |
| Imperial SS Flat Bar | 1/4″, 5/16″, 3/8″ 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/4″, 1 1/2″, 1 3/4″, 2”, 4″ |
Weight Calculator of Stainless Steel 304 Flat Bar
| Flat Bar Weight Calculation Formula | |
| Flat Bar Weight Formula 0.00623 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.0019 X ( mm ) Diam X ( mm ) Diam = Weight / Feet |
0.00788 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.00240 X ( mm ) Diam X ( mm ) Diam = Weight / Feet |
| Flat Bar Weight Forumla 0.00680 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.002072 X ( mm ) Width X ( mm ) Diam = Weight / Feet |
Flat Bar Weight Forumla 0.00798 X ( mm ) Thickness X ( mm ) Width = Weight / Meter 0.00243 X ( mm ) Width X ( mm ) Thickness = Weight |
