UNS N04400 Nickel Alloy Cooper Monel 400 Plate ASTM EN
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Monel 400 |
| Minimum Order Quantity | 500 kgs |
| Price | 15-20 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Monel 400 |
|---|---|---|---|
| Thickness | 0.6 - 30.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | UNS N04400 Nickel Alloy,Cooper Nickel Alloy,ASTM Monel 400 Plate |
||
Product Description
Uns N04400 Nickel Cooper Monel 400 Plate Nickel Based Alloy Plate / Sheet
Products Specification
| Product Name | Nickel Alloy Plate & Sheet |
| Thinckness |
Cold rolled:0.3mm-3mm Hot rolled: 3.0mm-30mm |
| Standard Size | Cold Rolled 1000*2000mm 1219*2438mm 1500*3000mm |
| Hot Rolled 1500*6000mm 1800*6000mm 2000*6000mm | |
| Service | Cutting (laser cutting, plasma cutting, cutting machine), Bending, forged produce |
| Surface Service | Raw finishing (2B NO.1) Finishing(HL 8K Checkered.etc) |
| Standard | ASTM, AISI, DIN, EN, GB, JIS |
| Mainly Grade | ASTM Grade: Incoloy 800 / 800H ,Incoloy 825,Inconel 600 , Inconel 625 , Inconel690,Hastelloy B , Hastelloy B-2 , Hastelloy C276 , Hastelloy C4, Hastelloy C2000, ASME Grade: N08800 N08810 N08825 N06600 N06601 N06690 N10001 N10665 N10276 N06455 N06625 EN 1.4588 2.4858 2.4817 2.4642 2.4617 2.4819 2.461 2.4856 |
| Brand | TISCO BAOSTEEL ZPSS LISCO JISCO |
1. Monel 400 Plates, Sheets & Coils
ASTM B127 Monel UNS No. N04400 / 5500 Chequered Plate, Shim Sheet & Coils, Circles Suppliers.
We are Manufacturers, Supplier and Exporters of Monel Plates, Sheets & Coils that are using high quality raw materials in Mumbai, India. We also offer a wide range of Monel 400, Monel K500 Plates, Sheets & Coils as per the clients requirements. These Monel sheets, plates and coils are manufactured in national & international standards. These are widely used in various application industry like Chemicals, Fats, & Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship Builders, Paper Industries etc. We are offering these plates, sheets & coils in below mentioned technical specifications.
2. Monel 400 Plates, Sheets & Coils Specification :
| Products | Monel 400 Alloy Plate & Sheet |
| Standards | ASTM GB DIN EN JIS |
| Type | Sheet, Plates, Coils, Flat, Strips, Profile, Blank ,Circle, Ring etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grades | Monel 400 Plates, Sheets & Coils - UNS N04400, Monel K500 Plates, Sheets & Coils - UNS N05500 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NU-30M | NA 13 | МНЖМц 28-2,5-1,5 | NiCu30Fe |
| Monel K500 | 2.4375 | N05500 | - | - | - | - | - |
Chemical Properties of ALLOY 400 (UNS N04400)
| C | MN | P | S | Si | Cr | Ni | Mo | Cu | Co | Cb+Ta | Fe | other |
| .3 max | 2.0 max | .02 max | . 024 max | .5 max | 63.0 max | 28-34 max | 2.5 max |
Mechanical Properties Of Monel Alloy 400 Plates :
| Condition | Tensile (ksi) | .2% Yield (ksi) | Elongation (%) | Hardness (HRB) |
| Annealed | 70-85 | 28-50 | 50-35 | 60-76 |
Stock Informations of our Monel 400 Products
| Products | Size | Type | Note |
| Monel 400 Sheet & Plate | 0.6 - 3.0mm x 1219 x 2438mm 4.0 - 20.0mm x 1500 x 6000mm |
cold rolled hot rolled |
Laser cutting service |
| Monel 400 bar | Diameter 6 - 50mm x 6m length Diameter 12 - 250mm x 6m Length |
Bright Bar Black Bar |
Cutting any length |
| Monel 400 Pipe | DN6-DN300 x SCH10-SCH160 | Seamless pipe | Cutting as request |
| Monel 400 Strip | 0.6 - 3.0mm x Width 10 - 1219mm x C | slit cutting | any size as request |
