EN 1.4319 EN ASTM JIS 301 Stainless Steel Plate 0.4-30mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 1.4319 |
| Minimum Order Quantity | 1 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | waterproof paper and wooden pallets packing |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Material | Stainless Steel Sheet |
|---|---|---|---|
| Grade | 1.4319 | Standard | EN 10088-2 |
| Thickness | 0.4 - 100mm | Width | 1000mm 1219mm 1500mm 2000mm |
| Surface | 2B NO.1 | Service | Cutting, Surface Finishing |
| Highlight | ASTM 301 stainless steel plate,EN 1.4319 301 stainless steel plate,30mm 301 ss sheet |
||
Product Description
EN 1.4319 Stainless Steel Sheet & Plate EN ASTM JIS 301 Stainless Steel Thickness 0.4 - 30.0mm Thickness
Specification of our EN 1.4319 Stainless Steel Plate
| Products | EN1.4319 Stainless Steel Plate Sheet |
| Thickness | cold rolled 0.4 - 5.0mm |
| hot rolled 3.0 - 100mm | |
| Width | cold rolled 1000mm 1219mm 1500mm |
| hot rolled 1500mm 1800mm 2000mm | |
| Surface | 2B BA NO.1 NO.4 8K HL |
| Brand | TISCO BAOSTEEL POSCO JISCO |
| Equal Grade | 1.4319 / 301 / SUS301 / S30100 |
| Other Grade | 201 202 304 309S 310S 316L 321 347 410 420 430 2205 2507 904L 254SMO.etc |
| Standard | EN 10088-2 ASTM A240 JIS G4303 |
| Service | Cutting , Surface Finishing |
| MOQ | 500 kgs |
| Packing | Wooden pallets and waterproof paper |
| Loading Port | Shanghai Port,China |
| FCL Qty | 25 Tons each 20ft and 40ft container |
EN 1.4319 stainless steel is an austenitic stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the solution annealed (AT) condition. 1.4319 is the EN numeric designation for this material. X5CrNi17-7 is the EN chemical designation.
It has a fairly high ductility among wrought austenitic stainless steels. In addition, it has a moderately low embodied energy and a moderately low base cost.
The graph bars on the material properties cards below compare EN 1.4319 stainless steel to: wrought austenitic stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
Stainless steel 1.4319 Chemical composition
Chemical composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 301 ASTM A666 | min. max. |
- 0.15 |
- 2.0 |
- 1.0 |
- 0.045 |
- 0.030 |
16.0 18.0 |
- | 6.0 8.0 |
- 0.10 |
| 301L JIS G4305 | min. max. |
- 0.03 |
- 2.0 |
- 1.0 |
- 0.045 |
- 0.030 |
16.0 18.0 |
- | 6.0 8.0 |
- 0.20 |
| 1.4318/301LN EN 10088-2 | min. max. |
- 0.03 |
- 2.0 |
- 1.0 |
- 0.045 |
- 0.015 |
16.5 18.5 |
- | 6.0 8.0 |
0.10 0.20 |
Stainless steel 1.4319 Mechanical Properties:
| Grade/Temper | Tensile Strength ksi (min.) |
Yield Strength 0.2% ksi (min.) |
Elongation -% in 50 mm (min.) |
| EN 1.4319 1/4 | 125 | 75 | 25 |
| EN1.4319 1/2 | 150 | 110 | 18 |
| EN1.4319 Full Hard | 185 | 140 | 9 |
EN1.4319 Stainless Steel Sheet maintenance:
(1) Regular cleaning and maintenance
(2) Pay attention to prevent the occurrence of the phenomenon of surface scratches
(3) Use soap, weak detergent or warm water to remove surface dust, dirt
(4) In addition to the surface of the binder with alcohol or an organic solvent (ether, benzene)
(5) Use neutral detergent or ammonia solution in addition to surface oil
(6) With 10% nitric acid or abrasive detergent in addition to the surface of the embroider caused by dirt.
