Heat Resistant Stainless Steel Plate EN 1.4833 X12CrNi23-13 3.0-30.0mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 1.4833 |
| Minimum Order Quantity | 1 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | waterproof paper and wooden pallets packing |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Product Details
| Products | Stainless Steel Plate | Material | Stainless Steel Sheet |
|---|---|---|---|
| Grade | 1.4833 | Standard | EN 10088-2 |
| Thickness | 0.4 - 100mm | Width | 1000mm 1219mm 1500mm 2000mm |
| Surface | 2B NO.1 | Service | Cutting, Surface Finishing |
| Highlight | Heat Resistant 3mm stainless steel plate,3mm stainless steel plate EN 1.4833,30.0mm mirror finish stainless steel plate |
||
Product Description
Heat Resistant EN 1.4833 Stainless Steel Plate X12CrNi23-13 Stainless Steel Thickness 3.0-30.0mm from TISCO
Specification of our EN 1.4833 Stainless Steel Plate
| Products | EN1.4833 Stainless Steel Plate Sheet |
| Thickness | cold rolled 0.4 - 5.0mm |
| hot rolled 3.0 - 100mm | |
| Width | cold rolled 1000mm 1219mm 1500mm |
| hot rolled 1500mm 1800mm 2000mm | |
| Surface | 2B BA NO.1 NO.4 8K HL |
| Brand | TISCO BAOSTEEL POSCO JISCO |
| Equal Grade | 309S / X12CrNi23-13 / 1.4833 |
| Other Grade | 201 202 304 309S 310S 316L 321 347 410 420 430 2205 2507 904L 254SMO.etc |
| Standard | EN 10088-2 ASTM A240 JIS G4303 |
| Service | Cutting , Surface Finishing |
| MOQ | 500 kgs |
| Packing | Wooden pallets and waterproof paper |
| Loading Port | Shanghai Port,China |
| FCL Qty | 25 Tons each 20ft and 40ft container |
Alloy 309/309S (UNS S30900/S30908) austenitic stainless steel is typically used for elevated temperature applications. Its high chromium and nickel content provides comparable corrosion resistance, superior resistance to oxidation, and the retention of a larger fraction of room temperature strength than the common austenitic Alloy 304,316L,321.
Chemical Composition of 1.4833 Stainless Steel(309S)
| C(％) | Si(％) | Mn(％) | P(％) | S(％) | Cr(％) | Ni(％) | N(%) |
| Max 0.15 | Max 1.00 | Max 2.00 | Max 0.045 | Max 0.015 | 22.0-24.0 | 12.0-14.0 | Max 0.11 |
| EU EN |
USA - |
Japan JIS |
France AFNOR |
England BS |
Russia GOST |
| X12CrNi23-13 |
309S S30908 |
SUS309S | Z15CN23-13 |
309S16 309S24 |
20KH23N13 |
| Proof strength Rp0.2 (MPa) |
Tensile strength Rm (MPa) |
Impact energy KV (J) |
Elongation at fracture A(%) |
Reduction in cross section on fracture Z(%) |
As-Heat-Treated Condition | Brinell hardness (HBW) |
|---|---|---|---|---|---|---|
| 912 (≥) | 462 (≥) | 44 | 12 | 11 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 222 |
| Property | Density kg/dm3 |
Temperature T °C/F |
Specific heat J / kgK |
Thermal conductivity W/mK |
Electric resistance µΩ·cm |
Modulus of elasticity kN/mm2 |
Expansion rate |
|---|---|---|---|---|---|---|---|
| 999 (≥) | 335 (≥) | 21 | 34 | 44 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 221 | |
| Temp. °C/°F |
Creep strain limit (10000h) (Rp1,0) N/mm2 |
Creep rupture strength (10000h) (Rp1,0) N/mm2 |
|||||
| 479 | 867 | 194 |
Physical properties of grade 1.4833 Stainless Steel Plate
| Product type | Products | Dimension | Processes | Deliver Status |
|---|---|---|---|---|
| Plates / Sheets | Plates / Sheets | 0.08-200mm(T)*W*L | Forging, hot rolling and cold rolling | Annealed, Solution and Aging, Q+T, ACID-WASHED, Shot Blasting |
| Steel Bar | Round Bar, Flat Bar, Square Bar | Φ8-1200mm*L | Forging, hot rolling and cold rolling, Cast | Black, Rough Turning, Shot Blasting, |
| Coil / Strip | Steel Coil /Steel Strip | 0.03-16.0x1200mm | Cold-Rolled & Hot-Rolled | Annealed, Solution and Aging, Q+T, ACID-WASHED, Shot Blasting |
| Pipes / Tubes | Seamless Pipes/Tubes, Welded Pipes/Tubes | OD:6-219mm x WT:0.5-20.0mm | Hot extrusion, Cold Drawn, Welded | Annealed, Solution and Aging, Q+T, ACID-WASHED |
Alloy 1.4833 can be used in a variety of applications including:
- Aircraft and jet engine parts
- Auto exhaust parts
- Heat exchangers
- Waste incinerators
- Glass blowing components
- Rotary kilns
- Furnace anchor bolts
