UNS S32750 2507 Duplex Steel Sheet 0.6-40.0mm Cold Rolled
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3-3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | 2507 duplex steel sheet,S32750 duplex steel sheet,40.0mm stainless steel plate |
||
Product Description
UNS S32750 Stainless Steel Sheet & Plate Duplex SS Sheet 2507 0.6-40.0mm BAOSTEEL
GENERAL PROPERTIES
Duplex 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity, and a low coefficient of thermal expansion. The high chromium, molybdenum, and nickel levels provide excellent resistance to pitting, crevice, and general corrosion.
Standards
ASTM/ASME ………. A240 – UNS S32750
EURONORM………… 1.4410 – X2 Cr Ni MoN 25.7.4
AFNOR……………….. Z3 CN 25.06 Az
Applications
- Oil and gas industry equipment
- Offshore platforms, heat exchangers, process and service water systems, fire-fighting systems, injection and ballast water systems
- Chemical process industries, heat exchangers, vessels, and piping
- Desalination plants, high pressure RO-plant and seawater piping
- Mechanical and structural components, high strength, corrosion-resistant parts
- Power industry FGD systems, utility and industrial scrubber systems, absorber towers, ducting, and piping
General Corrosion
- high chromium and molybdenum content of 2507 makes it extremely resistant to uniform corrosion by organic acids like formic and acetic acid.
- provides excellent resistance to inorganic acids, especially those containing chlorides.
- can be used in dilute hydrochloric acid.
- Pitting need not be a risk in the zone below the borderline in this figure, but crevices must be avoided.
Intergranural Corrosion
- Low carbon content greatly lowers the risk of carbide precipitation at the grain boundaries during heat treatment.
- Is highly resistant to carbide-related intergranular corrosion.
Stress Corrosion Cracking
- Duplex structure of 2507 provides excellent resistance to chloride stress corrosion cracking (SCC).
- Superior to 2205 in corrosion resistance and strength.
- 2507 is especially useful in offshore oil and gas applications and in wells with either naturally high brine levels or where brine has been injected to enhance recovery.
Pitting Corrosion
- Different testing methods can be used to establish the pitting resistance of steels in chloride-containing solutions.
Crevice Corrosion
- Highly resistant to crevice corrosion.
Chemical Properties
Typical values (Weight %)
| C | Cr | Ni | Mo | N | Others |
|---|---|---|---|---|---|
| 0.020 | 25 | 7 | 4.0 | 0.27 | S=0.001 |
Mechanical Properties
| Ultimate Tensile Strength, ksi | 116 min. |
|---|---|
| 0.2% Offset Yield Strength 0.2%, ksi | 80 min. |
| 0.1% Offset Yield Strength 0.2%, ksi | 91 min. |
| Elongation in 2 inches, % | 15 min. |
| Hardness Rockwell C | 32 max. |
| Impact Energy, ft.-lbs. | 74 min. |
Physical Properties
| Density | lb/in^3 | 0.28 |
|---|---|---|
| Modulus of Elasticity | psi x 10^6 | 29 |
| Coefficient of Thermal Expansion 68-212°F/°F |
x10^-6/°F | 7.2 |
| Thermal Conductivity | Btu/h ft °F | 8.7 |
| Heat Capacity | Btu/lb/°F | 0.12 |
| Electrical Resistivity | W-in x 10^-6 | 31.5 |
