UNS N08904 904L AISI 904 Hot Rolled Cold Rolled Stainless Steel Plate
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | Hot Rolled cold rolled stainless steel plate,AISI 904 cold rolled stainless steel plate,N08904 904l sheet |
||
Product Description
UNS N08904 / 904L / AISI904 Stainless Steel Sheet Cold Rolled Hot Rolled SS Plate
ASTM SAE AISI 904L Stainless Steel (UNS N08904)
AISI 904L stainless steel (UNS N08904) is a high alloy austenitic stainless steel. Compared with 316L, SS904L has lower carbon (C) content, higher chromium (Cr) content, and approximatively twice the nickel (Ni) and molybdenum (Mo) content of 316L, which makes it have higher high temperature oxidation resistance, pitting resistance, and resistance to reducing acid (eg, sulfuric acid). Nitrogen (N) can reduce the rate of chromium carbide precipitation, thereby reducing the sensitivity of sensitization, it also improve the resistance to pitting and crevice corrosion caused by chlorides. Especially its addition of copper (Cu) makes it useful for all concentrations of sulfuric acid.
Datasheet and Specification
The following data sheet summarizes the chemical composition, properties, heat treatment and equivalent grade of 904L stainless steel (SS904L).
Chemical Composition
The following data sheet gives SS 904L stainless steel chemical composition.
| Chemical Composition, % | |||||||||||||
| ASTM | UNS | Type | C, ≤ | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | Mo | N, ≤ | Cu | Notes (Product) |
| ASTM A276/A276M | UNS S08904 | 904L | 0.02 | 1.00 | 2.00 | 0.045 | 0.030 | 19.0-23.0 | 23.0-28.0 | 4.0-5.0 | 0.10 | 1.0-2.0 | Bars and Shapes |
| ASTM A240/A240M | Plate, Sheet, and Strip | ||||||||||||
Mechanical Properties
The following table lists 904L stainless steel (SS904L) mechanical properties such as yield strength, tensile strength, elongation and hardness.
| AISI ASTM 904L Steel Mechanical Properties | |||||||
| ASTM | AISI Type | Tensile Strength, MPa (ksi), ≥ | 0.2% Yield Strength, MPa (ksi), ≥ | Elongation in 50 mm (2 in.), %, ≥ | Rockwell Hardness (HRBW), ≤ | Product forms | Conditions |
| ASTM A276/A276M | 904L (UNS N08904) | 490 (71) | 220 (31) | 35 | – | Bars and Shapes | Annealed, Hot-finished or cold-finished |
| ASTM A240/A240M | 490 (71) | 220 (31) | 35 | 90 | Plate, Sheet, and Strip | ||
Heat Treatment
Annealing: The recommended annealing temperatures for 904L wrought steel is 1095 °C (2000 °F).
Corrosion
Type 304 stainless steel can handle mild foods and vegetables, but sauces and pickle liquors are more corrosive and can even cause pitting corrosion on type 316 stainless steel. In order to improve pitting resistance, high alloy 904L stainless steel (SS904L) should be considered.
Applications
904L stainless steel (SS904L) is used in petroleum, chemical, fertilizer, marine development towers, tanks, pipes and tubes and heat exchangers. and other watch manufacturers also use it to make watches.
SS 904L Equivalent Grade
The datasheet below summarizes 904L stainless steel equivalent grade such as European EN (German DIN EN, British BS EN, French NF EN…), Chinese GB, ISO, Japanese JIS standard.
| AISI 904L equivalent material | |||||||||||||||||
| US | European Union | ISO | Japan | China | Australia | India | Rusia | Korea | |||||||||
| Standard | Type | Standard | Grade (Steel Number) | Standard | ISO Name (ISO Number) | Standard | Grade | Standard | Grade | Standard | Grade | Standard | Grade | Standard | Grade | Standard | Grade |
| AISI SAE; ASTM | 904L (UNS N08904) | EN 10088-2; EN 10088-3 | X1NiCrMoCu25-20-5 (1.4539) | ISO 15510 | X1NiCrMoCu25-20-5 (4539-089-04-I) | JIS G4303 | SUS 890L | GB/T 20878; GB/T 4237; GB/T 3280 | 015Cr21Ni26Mo5Cu | ||||||||
