JIS G4305 Stainless Steel Sheet SUS444 0.4-10.0mm TISCO POSCO AISI444
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | G4305 0.4 mm stainless steel sheet,JIS 0.4 mm stainless steel sheet,AISI444 stainless steel plate 10mm |
||
Product Description
JIS G4305 SUS444 Stainless Steel Sheet Thickness 0.4 - 10.0mm TISCO POSCO AISI444 Stainless
444 Stainless steel sheet manufacturer
SUS444 (00Cr18Mo2) is a ferritic stainless steel with ultra-low carbon and nitrogen content, 18% chromium and 2% molybdenum, and high corrosion resistance.The yield strength of 444 is equivalent to 1.5 times of carbon steel and 6 times of fiberglass steel. It has outstanding advantages in shock resistance, snow resistance, wind pressure resistance and impact resistance.
SUS444 ferritic stainless steel has high thermal conductivity, about 130% ~ 150% of Cr-Ni austenitic stainless steel, which is very suitable for heat exchange purposes.
Small thermal expansion coefficient, the small unit is only 60% ~ 70% of chromium-nickel Olympic stainless steel, very suitable for hot expansion, cold shrinkage, thermal cycle conditions.
The steel has good plasticity and toughness and is suitable for drawing, rolling forming and stamping manufacturing.
Especially the application of corrosion resistance is the most excellent, in the high chloride medium corrosion resistance is better than ordinary ferrite stainless steel and Olympic stainless steel, generally do not produce chloride stress corrosion cracking.
When Ti and Mo elements are added, the resistance to pore and crevice corrosion is improved.
The steel can be welded by the method of welding ordinary stainless steel.
This kind of steel is especially suitable for food processing equipment, heat exchanger, water heater tank, water storage tank, solar energy collection panel, etc.
Equivalent Material of 444 Stainless Steel Sheet
| Grade | Euronorm | China GB | Japanese JIS | |
| No. | ||||
| 444 | 1.4521N | 00Cr18Mo2 | SUS444 | |
Standard Specification Of 444 Plate
| Thickness | 0.4 - 10.0mm | ||||||
| Width | 1000mm, 1219mm, 1500mm | ||||||
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | ||||||
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | ||||||
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | ||||||
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
||||||
444 stainless steel composition content.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 444 | Min. Max. |
≤0.025 | ≤1.00 | ≤1.00 | ≤0.04 | ≤0.03 | 17.5~19.5 | 1.75~2.5 | ≤1.00 | ≤0.035 |
444 Stainless steel sheet
1. Chemical composition
| C | Si | Mn | P | S | Ni | Cr |
| max0.025 | max1.00 | max1.00 | max0.04 | max0.03 | --- | 17.00-20.00 |
2. Mechanical properties
| Yield Strength | Tensile | Elongation | Hardness (HV) | Hardness (HRB) |
| ≥245 | ≥410 | ≥20 | ≤230 | ≤96 |
3. Standard: AISI, ASTM, GB, EN, DIN, JIS
4. Surface: 2B, NO.1, BA, NO.4, Hairline, SB, Mirror finish, Anti-skid, Cherkered etc.
5. Size: Thickness: 0.3-3mm (cold rolled), 3-40mm (hot rolled)
Width: 1000mm or 1219mm or 1240mm for cold rolled, 1500mm for hot rolled.
Length: As customers' request.
6. MOQ: 1 Ton
7. Payment terms: T/T or L/C
8. Packing: Seaworthy package with wooden or Iron pallets with the paper and the steel strip, or as customers' request.
9. Delivery time: Usually about 7 days after we confirming the order, or according to your quantity.
