SUS409L Sheet 2b 2D Finished Suh409L 409L Stainless Steel Sheet
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | Suh409L Stainless Steel Sheet,409L Stainless Steel Sheet |
||
Product Description
fSUS409L Sheet 2b 2D Finished Suh409L 409L Stainless Steel Sheet
AISI/SS 409L Sheet is also known as UNS S40900 or EN 1.4512 which is a stable version of grade 409 that is composed of chromium content and some amount of nitrogen and carbon. This type of stainless steel grade is widely used by manufacturers for manufacturing different applications and equipment. Grade 409L is a low-cost option for the corrosion resistant stainless steel. It even has a good combination of corrosion resistance and heat resistance that is an ideal choice for lightly corrosive applications or the environment.
| Products | 409L stainless steel sheet |
| Thickness | 0.5 - 12.0mm |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Surface | 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Width | 1000mm, 1219mm,etc. |
| Finish | 2D |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc. |
409L SS Sheets Exporter, 409L Stainless Steel CR Sheets, SS 409L HR Sheets, AISI 409L Sheets, Austenitic Stainless Steel 409L Sheet, ASME SA240 Grade 409L Sheets,SS Gr. 409L Sheets
Features of AISI/SS 409L Sheet
- Corrosion resistance
- Excellent resistance to the exhaust gas, high temperature, and atmospheric corrosion
- Good formability and excellent flexibility
- Low cost
- Durability
These sheets can easily withstand in high and elevated temperature without getting damaged. However, to prove its quality and durability there are various tests done as per the industrial norms and regulations.
Grade Specifications for Stainless Steel 409L Sheets
| Grade | WERKSTOFF NR. | UNS | JIS |
| SS 409L | 1.4512 | S40903 | SUH 409L |
Chemical Properties of SS 409L Sheets
| Grade | C (max) | Si (max) | Mn | Cr | Ni | P(max) | S (max) | Ni(max) | Other Elements |
| SS 409L | 0.03 | 1.00 | 1.00 | 10.50-11.70 | 1.5 max | 0.040 | 0.030 | 0.50 | Ti=6X(C+N)Min., 0.75Max |
Mechanical Properties of SS 409L Sheets
| Element | Tensile Strength % | Yield Strength % | Elongation | Hardness (HRB) max |
| SS 409L | 380 | 170 | 20 | 88 |
Testing
- Radiography test
- Macro and micro test
- Third party inspection
- Flaring test
- Flattening test
- PMI test
For all these tests, manufacturers provide approved test certificates. However, when all the tests are done a proper care is given towards the packaging section. These sheets are packed in different quality of packaging material so as to prevent AISI/SS 409L Sheet from damage.
