ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Product Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | 1.4002 Stainless Steel Sheet,04Cr13 Stainless Steel Sheet,2.5mm Stainless Steel Sheet |
||
Product Description
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
Product Information
Alloy 405 is a 12% chromium stainless steel designed to be used in the as-welded condition. Unlike the other grades of 12% chromium stainless, 405 is not vulnerable to extensive hardening through air cooling from high temperatures.
Stainless Steel 405 Plates Specifications:
| Specifications | ASTM A240, ASME SA240 |
| Standard | JIS, ASTM, AISI, GB, EN, DIN |
| Surface | 2B, 2D, BA, NO.4, NO.8, 8K, Mirror, Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Finish | Cold rolled, Hot rolled |
| Width | 1000-2000mm |
| Length | 1000-6000mm |
| Thickness | 0.40mm – 6.00mm |
Technical data
Grade Specifications for Stainless Steel 405 Sheets
Mechanical Properties of SS 405 Sheets
S 405 Plate Equivalent grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR |
| SS 301 | 1.4002 | S40500 | SUS 405 | Z4 CA 13 |
Chemical Properties of SS 405 Sheets
| ELEMENT | C | Mn | P | S | Si | Cr | Al | Fe |
| SS 405 | 0.080 max | 1.00 max | 0.040 max | 0.030 max | 1.00 | 13.00 | 0.2 | 85 |
Mechanical Properties of SS 405 Sheets
| Grade/Temper | Tensile Strength
ksi (min.) |
Yield Strength 0.2%
ksi (min.) |
Elongation -% in 50 mm (min.) |
| SS 405 | 448 MPa | 276 MPa | 25.00% |
S 405 Plate Equivalent grades
| JIS G4304 | ASTM | UNS | KS | EN10095 | AS | CNS |
| SUS405 | 405 | S40500 | STS405 | 1.4002 | 405 | 405 |
Applications that frequently use alloy 405 include, but are not limited to:
- Steam nozzles
- Partitions
- Annealing boxes
- Quenching racks
- Fabrications that cannot be annealed after welding
