ASTM A276 201 Stainless Steel Bar 2.0-30.0mm EN GB JIS Construction
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 2205 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Flat | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 310S 321 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | 10*3-200*20mm |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | Stainless Steel Bar 201,A276 Stainless Steel Bar,30.0mm stainless flat bar |
||
Product Description
ASTM A276 201 Stainless Steel Flat Bar / Flat Bar Thickness 2.0 - 30.0mm Flat Steel
Products Specification of our stainless stainless flat bar
| Type | Stainless Steel Flat Bar |
| Surface | Black,bright,rough turned,grinding,centreless Ground etc |
| Standard | GB,AISI,ASTM,DIN,EN,SUS,UNS etc |
| Diameter | 0.5-500mm |
| Technique | Hot Rolled,Cold Rolled,Cold Drawn,Forged |
| Tolerance | H8,H9 or as required |
| Grade | 200 series: 201,202,202Cu,204Cu |
| 300 series: 301,303/Cu,304/L/H,304Cu,305,309/S,310/S,316/L/H/Ti,321/H,347/H,330 | |
| 400 series: 409/L,410,416/F,420/F,430,431,440C,441,444,446 | |
| 600 series: 13-8ph,15-5ph,17-4ph,17-7ph(630,631),660A/B/C/D | |
| Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760,2304,LDX2101.LDX2404,LDX4404,904L | |
| Others: 153Ma,254SMo,253Ma,654SMo,F15,Invar36,1J22,N4,N6 etc | |
| Alloy : Alloy 20/28/31 | |
| Hastelloy: Hastelloy B / B-2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N | |
| Haynes: Haynes 230/556/188 | |
| Inconel: Inconel 100/600/601/602CA/617/625713/718738/X-750,Carpenter 20 | |
| Incoloy: Incoloy 800/800H/800HT/825/925/926 | |
| GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044 | |
| Monel: Monel 400/K500 | |
| Nitronic: Nitronic 40/50/60 | |
| Nimonic: Nimonic 75/80A/90 | |
| Nickle: Nickle 200/201 |
STAINLESS STEEL 201 FLAT BAR PRODUCT FORMS:
Flat plate, strips
STAINLESS STEEL 201 FLAT BAR TYPICAL APPLICATIONS:
Typical applications for Types 201 are cookware, hose clamps, piston rings, transit car structural member, transit car roofing/siding, thermal window spacers, air bag containers, and truck trailer posts and door frames.
STAINLESS STEEL 201 FLAT BAR PROCESSING:
The annealing temperature for Type 201 is between 1850-2000°F. Rapid cooling through the carbide precipitation range (1500 – 800 o F) is necessary to keep the carbides in solution and prevent sensitization. Type 201 is not hardenable by thermal treatment; it is only hardenable by cold working.
STAINLESS STEEL 201 FLAT BAR FORMING:
Type 201 has similar bending, forming and drawing characteristics to Type 301 stainless steel
STAINLESS STEEL 201 FLAT BAR WELDING:
Type 201 can be welded by all conventional methods applied to 18 percent chromium, 8 percent nickel steels. Filler metal of the conventional chromium-nickel analyses can be used. Like other austenitic stainless steels where carbon is not controlled below 0.03%, Type 201 is susceptible to intergranular corrosion in the weld heat affected zone.
STAINLESS STEEL 201 FLAT BAR CORROSION:
Type 201 is resistant to a wide variety of mild to moderately corrosive environments. It has corrosion resistance approaching that of Types 301and has been successfully substituted for 304 in many mild environments.
STAINLESS STEEL 201 FLAT BAR CHEMICAL PROPERTIES:
| Element | Type 201 |
|---|---|
| Carbon | 0.15x |
| Manganese | 5.5 - 7.5 |
| Sulfur | 0.03X |
| Phosphorus | 0.060x |
| Silicon | 1.0 x |
| Chromium | 16 - 18 |
| Nickel | 3.5 -5.5 |
| Nitrogen | 0.25x |
STAINLESS STEEL 201 FLAT BAR PHYSICAL PROPERTIES:
| Density (lb./ in^2) @ RT | 0.283 | |
|---|---|---|
| Modulus of Elasticity in Tension (psi x 10^6) | 28.6 | |
| Specific Heat (BTU/o F/lb.) | 32 to 212 oF | 0.12 |
| Thermal Conductivity (BTU/hr/ft^2/ft) | 212oF | 9.4 |
| Mean Coefficient of Thermal Expansion (in. x 10^-6 per o F) | 32 to 212oF | 8.7 |
| 32 to 600oF | 9.7 | |
| 32 to 1,000oF | 10.2 | |
| Electrical Resistivity (micro ohms - cm) | at 70oF | 69 |
| Melting Point Range (oF) | 2550/2650 | |
| Oxidation Resistance - Continuous Service(oF) | 1550 | |
| Oxidation Resistance - Intermittent Service(oF) | 1500 |
- Width:25mm to 60mm
- Thickness:5mm to 12mm
- Finish :Hot Rolled Annealed & Pickled (HRAP)
- Length:3 to 6 Meters / 12 to 20 feet
- End Finish :Both ends are marked with special colors.
- Size tolerance:A276/484 / DIN 1028 (Full specification mentioned below)
- Packing:Bars are packed in 1000 to 1,200 kgs bundles in waterproof HDPE cloths, Standard Export Seaworthy, Marking of Sizes, Grade, Net Wt, Gross Wt, No of pieces, POD, Origin should Mentioned on Each bundles
- Marking:Size, Grade, Manufacture name on Each Bars/Pieces
- Delivery:60-75 Days from the order finalization
- Marking:Size, Grade, Manufacture name on Each Bars/Pieces
- Grades:AISI 304 / 304L, 201, 202, 316
