Heat Resistant 310S Stainless Steel Flat Bar for Boiler Structure 1.4845 Stainless Flat Bar
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 2205 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Flat | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 310S 321 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | 10*3-200*20mm |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | 1.4845 Stainless Steel Flat Bar,Boiler Structure Stainless Flat Bar,1.4845 Stainless Flat Bar |
||
Product Description
Heat Resistant 310S Stainless Steel Flat Bar for Boiler Structure 1.4845 Stainless Flat Bar
Products Specification of our stainless stainless flat bar
| Products | Stainless Steel Flat Bar |
| Size | 20*3mm - 200*20mm |
| Length | 6m or as request |
| Tech | hot rolled / cold rolled |
| Main Grade | 201 304 304L 309S 310S 316L 316Ti 410 420 430 2205 2507 904L.etc |
| Standard | ASTN JIS GB EN |
| Service | cutting, surface finishing |
| MOQ | 500 kgs |
STAINLESS STEEL 310 FLAT BAR GENERAL PROPERTIES:
Alloy 310 is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weldability. It is typically used for elevated temperature applications as its high chromium and nickel content provide solid corrosion resistance, excellent resistance to oxidation, and superior strength in temperatures up to 2100°F. Due to its high chromium and nickel content, it is superior to 304 or 309 stainless in most environments.
STAINLESS STEEL 310 FLAT BAR APPLICATIONS:
The higher alloyed stainless steels generally have excellent strength at elevated temperatures along with outstanding resistance to creep deformation and environmental attack. Therefore, Alloy 310 is used widely in industries such as heat treatment and chemical processing. Some examples include:
- Furnace Parts
- Oil Burner Parts
- Heat Exchangers
- Welding Filler Wire and Electrodes
- Annealing Covers
- Combustion Tubes
- Fire Box Sheets
STAINLESS STEEL 310 FLAT BAR VALUE ADDED SERVICES:
- Need a special length?
- We can custom level 3/8″ thick x 72″ x 186″ from our plate line to reduce scrap
- Polish plate inventory available
- We supply #4, #6, and #8 mirror finish
- Special polishes available
- Plate processing
- Dynamic water jet cutting
- Plate shearing
- Saw cutting
- Plasma cutting and high quality plasma cutting
- Machine cut rings and discs
Penn Stainless Alloy 310 Plate and Processed Flat Bar provides superior resistance to corrosion and heat exposure, in even the most demanding environments.
STAINLESS STEEL 310 FLAT BAR CORROSION RESISTANCE:
- Provides excellent corrosion resistance
- High chromium content allows for good aqueous corrosion resistance
- Excellent resistance at normal temperatures and also has good resistance to oxidizing and carburizing atmospheres
STAINLESS STEEL 310 FLAT BAR HEAT RESISTANCE:
- Good resistance to oxidation in intermittent service in air at temperatures up to 1040°C and 1150°C in continuous service.
- Good resistance to thermal fatigue and cyclic heating.
- Widely used where sulphur dioxide gas is encountered at elevated temperatures.
- Continuous use in 425-860°C range not recommended due to carbide precipitation, if subsequent aqueous corrosion resistance is needed
- Generally used at temperatures starting from about 800 or 900°C – above the temperatures at which 304H and 321 are effective.
STAINLESS STEEL 310 FLAT BAR FABRICATION:
- Commonly used in the heat treatment and process industries due to high temperature and corrosive environments
- Often fabricated into complex structures
- Roller-forms, stamps and draws readily
- Because 310 work hardens, severe forming operations should be followed by an anneal
STAINLESS STEEL 310 FLAT BAR WELDABILITY:
- Austenitic stainless steel is generally considered to be weldable
- Generally considered to have weldability equivalent to 304 and 304L
- Special consideration is needed to compensate for a higher coefficient of thermal expansion to avoid warping and distortion
STAINLESS STEEL 310 FLAT BAR CHEMICAL PROPERTIES:
| % | Cr | Ni | C | Si | Mn | P | S | Mo | Cu | Fe |
|---|---|---|---|---|---|---|---|---|---|---|
| 310 | min: 24.0 max:26.0 |
min: 19.0 max: 22.0 |
0.25 | 0.75 | 2.0 | 0.045 | 0.030 | 0.75 | 0.5 | balance |
| 310S | min: 24.0 max: 26.0 |
min: 19.0 max: 22.0 |
0.08 | 1.00 | 2.0 | 0.045 | 0.030 | 0.75 | 0.5 | balance |
STAINLESS STEEL 310 FLAT BAR MECHANICAL PROPERTIES:
| Grade | Tensile Strength ksi (min.) |
Yield Strength 0.2% Offset ksi (min.) |
Elongation - % in 50 mm (min.) |
Hardness (Brinell) MAX |
Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 310/310S | 75 | 30 | 40 | 217 | 95 |
STAINLESS STEEL 310 FLAT BAR PHYSICAL PROPERTIES:
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Electrical Resistivity mW-in | Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Magnetic Permability (annealed)1 | Modules of Elasticity (annealed)2-psi | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| at 68 °F | at 68 – 212°F | at 68 – 932°F | at 68 – 1832°F | at 68°F | at 1200°F | at 68 – 1832°F | at 68 – 932°F | at 32 – 212°F | at 200H | in tension (E) | in shear (G) |
| 0.29 | 8.8 | 9.5 | 10.5 | 30.7 | — | 10.5 | 10.8 | 0.12 | 1.02 | 29 x 106 | 11.2 x 106 |
- Width:25mm to 60mm
- Thickness:5mm to 12mm
- Finish :Hot Rolled Annealed & Pickled (HRAP)
- Length:3 to 6 Meters / 12 to 20 feet
- End Finish :Both ends are marked with special colors.
- Size tolerance:A276/484 / DIN 1028 (Full specification mentioned below)
- Packing:Bars are packed in 1000 to 1,200 kgs bundles in waterproof HDPE cloths, Standard Export Seaworthy, Marking of Sizes, Grade, Net Wt, Gross Wt, No of pieces, POD, Origin should Mentioned on Each bundles
- Marking:Size, Grade, Manufacture name on Each Bars/Pieces
- Delivery:60-75 Days from the order finalization
- Marking:Size, Grade, Manufacture name on Each Bars/Pieces
- Grades:AISI 304 / 304L, 201, 202, 316
