TP347 SS Steel Tube 1.4550 DN10-DN300 SCH40 SCH80 XXS
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe Tube | Grade | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | TP347 ss steel tube,ss steel tube 1.4550,DN10 ss pipe tube |
||
Product Description
TP347 Stainless Steel Pipe 1.4550 Stainless Steel DN10 - DN300 With SCH40 SCH80 XXS
Type 347 / 347H stainless steel is an austenitic grade of chromium steel, which contains columbium as a stabilizing element. Tantalum can also be added for achieving stabilization. This eliminates the carbide precipitation, as well as intergranular corrosion in steel pipes. Type 347 / 347H stainless steel pipes offer higher creep and stress rupture properties than grade 304 and 304L. This makes them suitable for exposures to sensitization and intergranular corrosion. Moreover, the inclusion of columbium allows 347 pipes to have excellent corrosion resistance, even superior to that of 321 stainless steel pipes. However, 347H steel is the higher carbon composition substitute of stainless steel pipe grade 347. Therefore, 347H steel tubes offer improved high temperature and creep properties.
347 / 347H STAINLESS STEEL TUBE PROPERTIES
Following are the properties of 347 / 347H stainless steel pipes offered by Arch City Steel & Alloy:
Corrosion Resistance:
- Exhibits oxidation resistance similar to other austenitic stainless steels
- Preferred over grade 321 for aqueous and other low temperature environments
- Better high temperature properties than 304 or 304L
- Good resistance to sensitization in high temperature environments
- Suited for heavy welded equipment that cannot be annealed
- Used for equipment operated between 800 to 150°F (427 TO 816°C)
Weldability:
-
347 / 347H stainless steel tubes/pipes are considered to be the most weldable among all high grade steels pipes
-
They can be welded by all commercial processes
Heat Treatment:
-
347 / 347H stainless steel tubes and pipes offer an annealing temperature range of 1800 to 2000°F
-
They can be stress relief annealed without any danger of subsequent intergranular corrosion within the carbide precipitation range of 800 to 1500°F
-
Cannot be hardened by heat treatment
Applications:
347 / 347H pipes are frequently used for fabrication of equipment that ought to be used under severe corrosive conditions. Also, they are commonly used in petroleum refining industries. Major applications include:
- High temperature chemical processes
- Heat exchanger tubes
- High pressure steam pipes
- High temperature steam and boiler pipes/tubes
- Heavy duty exhaust systems
- Radiant superheaters
- General refinery piping
CHEMICAL COMPOSITION
| Typical Chemical Composition % (max values, unless noted) | ||||||||
| Grade | C | Cr | Mn | Ni | P | S | Si | Cb/Ta |
| 347 | 0.08 max | min: 17.0 max: 20.0 |
2.0 max | min: 9.0 max: 13.0 |
0.04 max | 0.30 max | 0.75 max | min:10x C max: 1.0 |
| 347H | min: 0.04 max: 0.10 |
min: 17.0 max: 20.0 |
2.0 max | min: 9.0 max: 13.0 |
0.03 max | 0.30 max | 0.75 max | min:10x C max: 1.0 |
MECHANICAL PROPERTIES
| Typical Room Temperature Mechanical Properties | |||||
| Grade | Tensile StrengthKSI (MPA) | Yield Strength 0.2% KSI offset KSI (MPA) | Elongation (% in 2ʺ(50.8 mm) | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
| 347/347H | 75 (515) | 30 (205) | 40 | 201 | 95 |
