Alloy 2.4819 Nickel Base Alloy Plate Sheet Hot Rolled & Cold Rolled HC276 Plate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 2.4819 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | 2.4819 |
|---|---|---|---|
| Thickness | 1.0 - 30.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
Product Description
Alloy 2.4819 Nickel Base Alloy Plate Sheet Hot Rolled & Cold Rolled HC276 Plate
Quick Informations
| Grade | Hastelloy C276 / 2.4819 | Type | Sheet, Plate |
| Thickness | 1.0-25.0mm | Width | 1219mm,1500mm |
| Length | Within 6m | Service | Laser Cutting |
More Specification Informations
| Products Name | DIN 2.4819 Nickel Alloy Sheet , Plate |
| Thickness | cold rolled 1.0 - 3.0mm, hot rolled 4.0 - 25.0mm |
| Standard Size | 1000*2000mm,1219*2438mm,1500*6000mm |
| Surface | 2B, NO.1 |
| Brand | DELTA |
| Service | Laser cutting |
| MOQ | 2 Kgs |
| Other Type | round bar, strip,coil,pipe.etc |
| Packing | waterproof paper and wooden pallets, wooden box |
| Loading Port | Shanghai Port |
| Price term | EXW,FOB,CIF,CFR |
| Deliver time | within 12 days |
Comprehensive Product Datasheet: DIN 2.4819 (Hastelloy® C-276) Nickel Alloy Plate
1. Product Overview
DIN 2.4819 (trade names: Hastelloy® C-276, UNS N10276, W.Nr. 2.4819) is a nickel-molybdenum-chromium superalloy engineered for extreme corrosion resistance. As a solution-strengthened, low-carbon alloy, it excels in oxidizing and reducing environments, making it ideal for critical applications in chemical processing, pollution control, and marine engineering138.
2. Key Chemical Composition
| Element | Composition (wt.%) | Role |
|---|---|---|
| Ni | Balance (~50-60%) | Base matrix, ductility |
| Mo | 15.0-17.0 | Resistance to reducing acids (e.g., HCl, H₂SO₄) |
| Cr | 14.5-16.5 | Oxidation resistance |
| W | 3.0-4.5 | Enhances pitting resistance |
| Fe | 4.0-7.0 | Cost efficiency |
| C, Si | ≤0.02, ≤0.08 | Ultra-low to prevent intergranular corrosion |
| Trace elements (Co, V, Mn, P, S) tightly controlled for purity358. |
3. Outstanding Properties & Performance
3.1 Corrosion Resistance: The Ultimate Shield
-
Acid Resistance: Withstands sulfuric, hydrochloric, phosphoric, and organic acids (e.g., acetic, formic) at concentrations ≤65% and temperatures up to boiling point58.
-
Chloride Immunity: Exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking (SCC) in seawater, brine, and chlorinated solvents14.
-
Unique Capability: One of few alloys suitable for wet chlorine, hydrofluoric acid (HF), and flue gas desulfurization (FGD) scrubbing37.
3.2 Mechanical & Physical Properties
| Property | Value |
|---|---|
| Density | 8.90–9.24 g/cm³ |
| Melting Point | 1325–1370°C |
| Tensile Strength | 690–735 MPa |
| Yield Strength (0.2%) | 285–310 MPa |
| Elongation | ≥40% |
| Hardness (Brinell) | ≤230 HB |
| Maintains strength from cryogenic temperatures to 550°C; avoid prolonged use above 700°C due to aging embrittlement349. |
3.3 Fabrication Advantages
-
Weldability: Compatible with TIG, MIG, plasma arc, and SMAW. No post-weld heat treatment required8.
-
Formability: Excellent cold/hot workability via rolling, forging, and deep drawing68.
4. Target Applications
| Industry | Key Components |
|---|---|
| Chemical Processing | Reactors, evaporators, acid-handling systems |
| Pollution Control | FGD scrubbers, dampers, flue gas reheaters |
| Marine & Offshore | Seawater pipelines, submarine components |
| Pharma/Pulp & Paper | Bleach equipment, waste treatment tanks |
| Energy | Nuclear coolant systems, heat exchangers147 |
5. Sales Advantages & Supply Capabilities
5.1 Competitive Selling Points
-
⛑️ Zero Intergranular Corrosion: Ultra-low C/Si eliminates carbide precipitation in weld heat-affected zones (HAZ), ensuring structural integrity in welded assemblies35.
-
