12Cr1MoV Alloy Steel Plates & Sheets Pressure Vessel Steel Plate SA387 P11

Place of Origin	China
Brand Name	BAOSTEEL BENSTEEL HBIS XINGCHENG
Certification	ISO 9001
Model Number	Carbon Steel , Alloy Steel
Minimum Order Quantity	500 kgs
Price	550 - 850 USD/Ton
Packaging Details	standard packing for export
Delivery Time	5 - 12 days based on the quantity
Payment Terms	L/C, T/T, Western Union
Supply Ability	20Ton per week

Product Details

Products	Steel Plate	Thickness	3.0 - 200.0mm
Width	1000-2200mm	Length	2000-12000mm
Standard	ASTM EN GB	Other Material	Carbon Steel, Alloy Steel, Stainless Steel
Brand	BAOSTEEL XINYU XINGCHENG HBIS	Service	Cutting
Highlight	Pressure Vessel Steel Plates , SA387 P11 Steel Plates , 12Cr1MoV Alloy Steel Plates

Leave a Message

Product Description

12Cr1MoV Alloy Steel Plates & Sheets Pressure Vessel Steel Plate SA387 P11

12Cr1MoV steel is a low-alloy steel known for its excellent high-temperature strength, corrosion resistance, and ability to withstand high pressure. Due to these properties, it is widely used in industries like power generation, petrochemicals, and boilers. This article explores the key features, applications, and benefits of 12Cr1MoV steel plates.

Products Specification of our plate

Products	Alloy Steel Plate
Specification	Length	2000mm, 2438mm, 3000mm, 3500mm,6000mm, 12000mm,or rolled,etc etc
	Thickness	3.0 - 200mm,etc
	Width	1000-2500mm or cutting any width as request
Material	Q235,Q255,Q275,SS400,A36,SM400A,St37-2,SA283Gr,S235JR,S235J0,S235J2,1cr6si2mo,1cr5mo,15crmo,12cr1mov,15cdv6
Standard	ASTM,AISI,JIS,GB, DIN,EN
Technique	Hot rolled / cold rolled
Surface	Black Finish ,Oiled,Shot Blasted,Spray Paint,Coated,Galvanized,Or as Your Request
Package	standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Payment Term	T/T, L/C at sight,West Union,Paypal
Price Term	FOB,CRF,CIF,EXW all acceptable

12Cr1MoV alloy steel plates Chemical Composition

Grade	C	Si	Mn	Cr	Mo	Ni	W	B	Al	Ti	V
12Cr1MoV	0.08-0.15	0.17-0.37	0.40-0.70	0.90-1.20	0.25-0.35	～	～	～	～	～	0.15-0.30

12Cr1MoV alloy steel plates Mechanical Property

GRADE	Yield Strength (MPa) min.	Tensile Strength (MPa)	Elongation min. %	rate of reduction in area %	Shock absorption energy	Hardness HBW
min.					max.
12Cr1MoV	490	245	22	50	71	179

12Cr1MoV alloy steel plates12Cr1MoV alloy steel plates Application

12Cr1MoV alloy steel plates are widely used for high pressure, extra high pressure and sub critical power plant boiler and superheat

12Cr1MoV alloy steel plates12Cr1MoV alloy steel plates Other Name

12Cr1MoV alloy Steel Metal Plate Sheet, 12Cr1MoV alloy carbon steel plate , Boiler and pressure vessel steel plate 12Cr1MoV, Boiler and pressure vessel steel 12Cr1MoV Container plate, 12cr1mov alloy steel plate, 12cr1mov pressure vessel steel plate

12Cr1MoV alloy steel platesAdditional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting
