Laser Cutting Inconel 600 Plate & Sheet ASTM B168 Standard With EN 10204-3.1 Certificate Alloy 600 Plates
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | inconel 600 |
| Minimum Order Quantity | 500 kgs |
| Price | 25-30 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Inconel 600 |
|---|---|---|---|
| Thickness | 0.4 - 80mm | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | ASTM B168 Inconel 600 Plate,EN 10204-3.1 Inconel 600 Plate,Laser Cutting Inconel 600 Plate |
||
Product Description
Laser Cutting Inconel 600 Plate & Sheet ASTM B168 Standard With EN 10204-3.1 Certificate Alloy 600 Plates
| Material | Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy |
| Shape | Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet |
|
Grade |
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L |
| Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc | |
| Alloy : Alloy 20/28/31 | |
| Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g | |
| Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C, Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665 |
|
| Haynes: Haynes 230/556/188 | |
| Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20 | |
| Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851, Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816 |
|
| Incoloy: Incoloy 800/800H/800HT/825/925/926; | |
| GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044 | |
| Monel: Monel 400/K500/R405 | |
| Nitronic: Nitronic 40/50/60; | |
| Nimonic: Nimonic 75/80A/90/A263 ; | |
|
Specification |
Wire: 0.01-10mm Strip: 0.05*5.0-5.0*250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm |
| Product Characteristics |
1.According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc.. |
| Standard | GB,AISI,ASTM,DIN,EN,SUS,UNS etc |
| Inspection | ISO,SGS,BV,PMI and so on. |
ABOUT ALLOY 600
With high nickel content, Inconel Alloy 600 is virtually immune to chloride-induced stress corrosion cracking. The alloy has superb corrosion resistance to caustic environments and resistance to dry chlorine up to 538°C.
This alloy has excellent oxidation resistance up to 1093°C combined with high carburisation resistance and demonstrates good performance in high temperature nitriding environments.
It is not recommended that Inconel® Alloy 600 be used at red heat temperatures where sulphur is present. It has also been found that Inconel® Alloy 600 can fall victim to stress corrosion cracking in hot, concentrated caustic alkalis, however, this can be avoided if the fabrication is fully stress relieved before use. Recommended stress relieving temperature of 982-1010 °C for 1 hour yields the best performance.
Inconel 600 Sheets & Plates Equivalent Grade
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Inconel 600 Sheets & Plates Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
Inconel 600 Sheets & Plates Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Alloy 600 can be used in a variety of applications including:
- Heat treating muffles and retorts
- Vacuum furnace fixtures
- Nitriding furnaces and baskets
- Chlorination equipment to 538°C
- Titanium dioxide plants
Other Types of Inconel Alloy 600 Sheets & Plates
| Inconel 600 Sheets | Grade Alloy 600 Plates | 600 Inconel Cold Rolled Sheet |
| Inconel 600 Shim Sheets | Alloy 600 Perforated Plates | Alloy 600 Hot Rolled plate |
| Inconel 600 ASME SB168 Sheets | Inconel 600 Finish #4 Plates | Inconel Grade 600 2B Finish Plates |
| UNS N06600 Perforated Sheets | Alloy GR 600 Circles | DIN 2.4816 Plain Sheet |
| UNS N06600 Circles | Alloy 600 Slatted Sheets | Inconel 600 Chequered Plates |
| Inconel Grade 600 Plain Sheets | Inconel 600 Chequered Plate | DIN 2.4816 Foils |
| ASTM B168 Inconel 600 Coils | ASTM B168 Inconel 600 Coils | Inconel Gr 600 Polished Plates |
| AMS 5511 Gr 600 Sheets | Mirror Finish Inconel 600 Sheet | 600 Inconel Outokumpu Sheet |
| Inconel 600 Sheet at Best Price in India | ASME SB168 600 Inconel Custom Cut Plate | Type 600 Inconel Perforated Sheet |
| Alloy 600 Plate Price in India | Alloy Inconel 600 Plate Stock | 600 Inconel sheets Sizes |
| Alloy Inconel 600 Shim Stock | Inconel 600 Plate Equivalent | 600 inconel sheet gauge |
| gr 600 inconel plate thickness | 1/4 inconel 600 plate | inconel 600 sheet sizes |
