SCr440 Alloy Steel Plate JIS Standard Steel Plate & Sheets 41Cr4 Thickness 10.0 - 150.0mm
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO 9001 |
| Model Number | AISI5140 / 1.7035 / 40Cr / 41Cr4 |
| Minimum Order Quantity | 500 kgs |
| Price | 780 - 940USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | AISI5140 Alloy Steel Plate | Thickness | 4.0 - 150.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Grade | 4140 / 5140 / |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | SCr440 Sheets Steel Plate,41Cr4 Steel Plate,JIS Standard Steel Plate |
||
Product Description
SCr440 Alloy Steel Plate JIS Standard Steel Plate & Sheets 41Cr4 Thickness 10.0 - 150.0mm
Products Specification of Steel Plate
| Products Name | AISI 5140 / 1.7035 Alloy Steel Plate |
| Thickness | 4.0 - 150.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
SCr440 alloy steel is a structural alloyed steel which contains 1.0% Cr as per JIS G4104 standard .Compared with S40C steel,it has better strength and hardenability,but may crack when welding. SCr440 is widely used in Low and moderately stressed parts for vehicles, engines and machines where hard, wear resisting surface is needed. The hardness as surface hardened can achieve to 54 HRC.
Chemical Composition of SCr440 Alloy Steel
| Grade | C | Mn | Si | Cr | P | S |
| SCr440 | 0.38-0.43 | 0.6-0.85 | 0.15-0.35 | 0.9-1.2 | ≤ 0.03 | ≤ 0.03 |
| 5140 | 0.38-0.43 | 0.7-0.9 | 0.15-0.35 | 0.7-0.9 | ≤ 0.035 | ≤ 0.04 |
SCr440 Steel Mechanical Property With Quenching and Tempering
| Tensile Strength | Yield Strength | Elongation | Reduction of Area | Impact Charpy-V | Hardness |
| ≥932Mpa | ≥784Mpa | ≥13% | ≥45% | ≥59J | 269-331HB |
We can also supply SCr440 Alloy Steel Round Bars
- Shape:Round / Square / Flat Bars, Shafts, Rollers, Blocks.
- Forged round bar
- Diameter: 80-1,000mm
- Length: 3,000-10,000mm
- Rolled round bar
- Diameter: 10-300mm
- Length: 3,000-10,000mm(can be customized)
- Forged square bar
- Size: 150×150-600×600mm
- Length: 3,000-8,000mm
- Surface condition: Black/Peeled/Smooth Turned
Our Cutting Service
- Cutting method: Plasma cutting
- Cutting tolerance: ±5mm
- Cutting Width: within 3000mm
- Cutting Length: within 12000mm
- Cutting Edge: Smooth without burr
FAQ
Q1: What is your terms of payment?
A: 30% T/T in advance, the balance 70% before delivery. We will show you the photos of products and package before you pay the balance.
Q2: what is the terms of delivery?
A: EXW, FOB, CIF, CFR, DDU
Q3: What is the terms of packing?
A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit. For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q5: Could you provide the samples?
A: yes, we could provide the free samples on conditons it is available in stocks, however, the the transportation fee is borne by buyer.
Q6: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Lenser piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
A: EXW, FOB, CIF, CFR, DDU
Q3: What is the terms of packing?
A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit. For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q5: Could you provide the samples?
A: yes, we could provide the free samples on conditons it is available in stocks, however, the the transportation fee is borne by buyer.
Q6: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Lenser piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
