EN 10088-2 1.4568 Stainless Steel Sheets & Coils 0.3 - 3.0mm Cold Rolled & Hot Rolled 631 Alloy
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 631 / 1.4568 |
| Minimum Order Quantity | 500 kgs |
| Price | 3300 - 3480 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 631 / 1.4568 |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | 631 cold rolled stainless steel sheet,0.3mm cold rolled stainless steel sheet,1.4568 cold rolled stainless steel sheet |
||
Product Description
EN 10088-2 1.4568 Stainless Steel Sheets & Coils 0.3 - 3.0mm Cold Rolled & Hot Rolled 631 Alloy
Products Specification
|
Product Name
|
631 Stainless Steel Sheets
|
|
Material Type
|
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
|
|
Grade
|
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
|
|
200series:201,202,202cu,204
|
|
|
400series:409,409L,410,420,430,431,439,440,441,444
|
|
|
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
|
|
|
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
|
|
|
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
|
|
|
Technology
|
Cold Rolled /Hot Rolled
|
|
Length
|
2000/2438/2500/3000/3048 mm
|
|
Width
|
1000/1219/1250/1500 mm
|
|
Thickness
|
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
|
|
|
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
|
|
Leveling: improve flatness, esp. for items with high flatness request.
|
|
|
Skin-Pass: improve flatness, higher brightness
|
|
|
Other Choices
|
Cutting:Laser cutting, help the customer to cut the required size
|
|
Protection
|
1. Inter paper available
|
|
2. PVC protecting film available
|
|
|
Price Item
|
FOB,CIF,DDU,FCA,EXW ,.etc
|
|
Quality Assurance
|
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent
|
631 / 17-7PH Stainless Steel Sheets in Stock
| 631 / 17-7PH Stainless Steel Sheets Thickness | |||||||
| 0.3mm | 0.4mm | 0.5mm | 0.6mm | 0.8mm | 1.0mm | 1.2mm | 1.5mm |
| 2.0mm | 2.5mm | 3.0mm | 4.0mm | 5.0mm | 6.0mm | 8.0mm | 10.0mm |
| 12.0mm | 14.0mm | 16.0mm | 20.0mm | 22.0mm | 25.0mm | 28.0mm | 30.0mm |
About 17-7PH Stainless Steel Sheets
17-7Ph is a type of Austenitic-Martensite precipitation hardened stainless steel developed base on 18-8CrN,that’s 631 stainless steel. After solid solution treatment, stainless steel 17-7ph will become unstable Austenite tissue, then cooling to precipitate carbide, and then Martensite transformation will be conducted. Most of the tissues will be transformed into low-carbon tempered Martensite with better toughness. The corrosion resistance of 17-7PH is better than that of ordinary Martensitic stainless steel.
17-7PH is characterized by high strength and hardness, excellent fatigue properties, good corrosion resistance and minimum distortion on heat treatment after heat treatment. The molding properties and elasticity of annealed 17-7PH are similar to 301. Under heat treatment conditions of TH1050 and RH950, the corrosion resistance of 631 is better than that of ordinary hardened stainless steels (such as 410, 420 and 431), but not as good as 304. After heat treatment, the corrosion resistance of CH900 is similar to 304 in most environments.
Chemical composition of 17-7PH / 631 / 1.4568 Stainless Steel
| C | Mn | Si | Cr | Ni | P | S | Al |
| ≤0.09 | ≤1.00 | ≤1.00 | 16.0~18.0 | 6.5~7.75 | ≤0.04 | ≤0.03 | 0.75~1.5 |
Our 17-7PH / 631 / 1.4568 Stainless Steel Products
- AMS 5568 Welded Tubing
- AMS 5528 Sheet, Strip and Plate
- AMS 5529 Sheet, Strip Cold Rolled
- AMS 5644 Bars and Forgings (Cap. ASTM A 564 Type 631)
- AMS 5678 Wire
- AMS 5824 Welding Wire
- ASTM A 693, ASTM A 313, ASTM A 564, ASTM A 579 and ASTM A 705
- ASME SA 564, SA 693 and SA 705
Applications:
- Chemical processing equipment
- Aerospace applications
- Oil and petroleum refining equipment
- Food processing equipment
