ASTM A240/240M-20a AISI347H High Carbon Austenitic Stainless Steel Sheets & Plates
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 347H |
| Minimum Order Quantity | 500 kgs |
| Price | 3300 - 3480 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 347H |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | TISCO stainless flat sheet,AISI347H stainless flat sheet,ASTM A240 stainless flat sheet |
||
Product Description
ASTM A240/240M-20a AISI347H High Carbon Austenitic Stainless Steel Sheets & Plates from TISCO
Products Specification
|
Product Name
|
347H Stainless Steel Sheets
|
|
Material Type
|
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
|
|
Grade
|
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
|
|
200series:201,202,202cu,204
|
|
|
400series:409,409L,410,420,430,431,439,440,441,444
|
|
|
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
|
|
|
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
|
|
|
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
|
|
|
Technology
|
Cold Rolled /Hot Rolled
|
|
Length
|
2000/2438/2500/3000/3048 mm
|
|
Width
|
1000/1219/1250/1500 mm
|
|
Thickness
|
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
|
|
|
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
|
|
Leveling: improve flatness, esp. for items with high flatness request.
|
|
|
Skin-Pass: improve flatness, higher brightness
|
|
|
Other Choices
|
Cutting:Laser cutting, help the customer to cut the required size
|
|
Protection
|
1. Inter paper available
|
|
2. PVC protecting film available
|
|
|
Price Item
|
FOB,CIF,DDU,FCA,EXW ,.etc
|
|
Quality Assurance
|
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent
|
347 stainless steel is a columbium stabilized austenitic stainless steel grade with good general corrosion resistance and somewhat better resistance in strong oxidizing conditions than 321 (UNS S32100). It has excellent resistance to intergranular corrosion after exposure to temperatures in the chromium carbide precipitation range of 800 – 1500°F (427 – 816°C). The alloy has good oxidation resistance and creep strength to 1500°F (816°C). It also possesses good low-temperature toughness.
347H stainless steel is the higher carbon (0.04 – 0.10) version of the alloy. It was developed for enhanced creep resistance and higher strength at temperatures above 1000°F (537°C).
347/347H Stainless Steel Chemical Properties
| C | Cr | Mn | Ni | P | S | Si | Cb/Ta | |
|---|---|---|---|---|---|---|---|---|
| 347 | 0.08 Max | Min: 17.0 Max: 20.0 |
2.0 Max | Min: 9.0 Max: 13.0 |
0.04 Max | 0.30 Max |
0.75 Max |
Min:10x C Max: 1.0 |
| 347H | Min: 0.04 Max: 0.10 |
Min: 17.0 Max: 20.0 |
2.0 Max | Min: 9.0 Max: 13.0 |
0.03 Max | 0.30 Max |
0.75 Max |
Min:10x C Max: 1.0 |
347/347H Stainless Steel Mechanical Properties
| Grade | Tensile Strength Ksi (MPa) Min | Yield Strength 0.2% Ksi Offset Ksi (MPa) Min | Elongation (% In 50mm) Min | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 347/347H | 75 (515) |
30 (205) |
40 | 201 | 95 |
347H Stainless Steel Sheets and Plates in Stock
| Cold Rolled 347H Stainlesss Steel Sheets | |||
| 0.3*1219*2438mm | 0.4*1219*2438mm | 0.5*1219*2438mm | 0.6*1219*2438mm |
| 0.8*1219*2438mm | 1.0*1219*2438mm | 1.2*1219*2438mm | 1.5*1219*2438mm |
| 2.0*1219*2438mm | 2.5*1219*2438mm | 3.0*1219*2438mm | |
| Hot Rolled 347H Stainless Steel Plates | |||
| 3.0*1500*6000mm | 4.0*1500*6000mm | 5.0*1500*6000mm | 6.0*1500*6000mm |
| 8.0*1500*6000mm | 10.0*1500*6000mm | 12.0*1500*6000mm | 14.0*1500*6000mm |
| 16.0*1500*6000mm | 18.0*1500*6000mm | 20.0*1500*6000mm | 25.0*1500*6000mm |
| 30.0*1500*6000mm | 35.0*1500*6000mm | 40.0*1500*6000mm | 45.0*1500*6000mm |
|
Chemical composition and mechanical properties of stainless steel
|
|||||||||
|
Grade
|
Chemical Composition (%)
|
Mechanieal Performece
|
|||||||
|
C
|
Si
|
Mn
|
P
|
S
|
Ni
|
Cr
|
Mo
|
Hardness
|
|
|
201
|
≤0.15
|
≤1.00
|
5.5/7.5
|
≤0.060
|
≤0.030
|
3.5/5.5
|
16.0/18.0
|
-
|
HB≤241,HRB≤100, HV≤240
|
|
304
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
8.0/11.0
|
18.00/20.00
|
-
|
HB≤187,HRB≤90,HV≤200
|
|
316
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10.00/14.00
|
16.0/18.0
|
2.00/3.00
|
HB≤187, HRB≤90 HV≤200
|
|
316L
|
≤0.03
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10.00/14.00
|
16.0/18.0
|
2.00/3.00
|
HB≤187, HRB≤90 HV≤200
|
|
410
|
≤0.15
|
≤1.00
|
≤1.25
|
≤0.060
|
≤0.030
|
≤0.060
|
11.5/13.5
|
-
|
HB≤183, HRB≤88 HV≤200
|
|
430
|
≤0.12
|
≤1.00
|
≤1.25
|
≤0.040
|
≤0.03
|
-
|
16.00/18.00
|
-
|
HB≤183, HRB≤88 HV≤200
|
FAQ
Q: Are you a manufacturer?
A: Yes , we are a manufacturer, We have own factory, which is located in TIANJIN,CHINA. We have a leading power in producing and exporting galvanized steel coil,galvalume steel coil,ppgi etc. We promise that we are what you are looking for.
Q:Can we visit your factory ?
A:Warmly welcome once we have your schedule we will pick you up .
Q: Do you have quality control?
A: Yes, we have gained BV, SGS authentication.
Q: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to
quantity.
Q:How can we get the offer?
A:Please offer the specification of the product,such as material,size,shape,etc.So wecan give the best offer.
Q:Can we get the some samples?Any charges?
A:Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost.
Q: How do you make our business long-term and good relationship ?
A: 1.We keep good quality and competitive price to ensure our customers' benefit.
2.We respect every customer as our friend and we sincerrly do business and make friends with them, no matter where they come from.
