AR400 Abrasion Resistat Steel Plate ASTM standard Quenched & tempered Steel Plates
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO |
| Model Number | AR400 / Hardox 400 / NM400 |
| Minimum Order Quantity | 500 kgs |
| Price | 820 - 945 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Wear Resistant Steel Plate | Thickness | 4.0 - 40.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Grade | AR400 / AR450 / AR500 / AR600 |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | abrasion resistant steel plate,wear resistant steel plate,wear resistant plate |
||
Product Description
AR400 Abrasion Resistat Steel Plate ASTM Standard Quenched & Tempered Steel Plates
Products Specification of Wear Resistant Steel Plate
| Products Name | AR400 / NM400 Steel Plate |
| Thickness | 4.0 - 40.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
A514 AR400 abrasion resistant steel plate is a good candidate for some processing techniques. This material is characterized by a smooth, dark scale finish with a hardened surface. While not a good candidate for forming and machining, AR400 plate is suitable for welding. Intended for moderate wear applications, common uses include contact surfaces, hoppers, cement mixer drums and fins, and shooting targets. ASTM A514 is the standard specification for high yield, quenched and tempered alloy steel plate, suitable for welding.
AR400 Chemical Component
| Element | Brand | C | Si | Mn | P | S | Cr | Mo | Ni | B | CEV |
| Grade | |||||||||||
| AR400 | DELTA | ≤0.25 | ≤0.70 | ≤1.60 | ≤0.025 | ≤0.010 | ≤1.4 | ≤0.50 | ≤1.00 | ≤0.004 |
AR400 Mechanical Properties
| Grade | Class | Hardness (HB) | 20°CAKV(Portrait)J |
| AR400 | A | 360~430 | |
| AR400 | B | 360~430 |
The measured values of steel plate tensile properties Rp0.2, Rm and A50 are provided.
The measured values of longitudinal impact of steel plate at 0°C and -20°C are provided.
Hardness is divided into: Rockwell hardness, Brinell hardness, Vickers hardness, Richwell hardness, Shore hardness, Barinell hardness, Nooul hardness, Weinwell hardness. Vickers hardness is expressed by HV, Rockwell hardness can be divided into HRA, HRB, HRC, HRD, Brinell hardness is expressed by Hb [N(KGF /mm2)] (HBSHBW) (refer to GB/T231-1984). It is not a simple physical concept to measure the hardness of steel parts after annealing, normalizing and tempering by Brinell hardness method in production.
It is a comprehensive index of mechanical properties such as elasticity, plasticity, strength and toughness of materials. Hardness test according to the different test methods can be divided into static pressure method (such as Brinell hardness, Rockwell hardness, Vickers hardness, etc.), scratch method (such as Mohr hardness), bounce method (such as Shore hardness) and micro hardness, high temperature hardness and other methods.
Properties of AR400 Steel Plate
In addition to its general characteristics of being formable, while maintaining good abrasion resistance, AR400 steel also has the following mechanical properties:
- Machining = Fair
- Bending = Good
- Corrosion Resistance = Good
- Welding = Excellent
- Wear Resistance = Great
- Excellent resistance to both impact and sliding abrasion at a moderate cost.
- Recommended for: liners for mining and material handling equipment like dump trucks, material transfer chutes, storage bins, buckets, and hopper
- .125″-.315 offered in 48″-65″ wide cut to your requested length
- .375”-2.00” offered in standard sizes (96″ X 240″/288”)
Benefits of AR400 Steel Plate
When zeroing in on what abrasion resistant steel is best for your applications, it’s important to note that each grade reacts differently to many fabricating processes. AR400 steel plate is excellent for applications in which abrasion resistance is required, but formability and weldability are a must. Because of these properties, it can be used for a variety of different applications. It is particularly good in applications where there may be impact or sliding abrasion
