EN 1.4510 / AISI439 Stainless Steel Sheet & Plate from TISCO POSCO
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 439 |
| Minimum Order Quantity | 500 kgs |
| Price | 1410-1620USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | Stainless Steel 439 |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | rolled sheet metal,400 series stainless plate,thin ss plate |
||
Product Description
EN 1.4510 / AISI439 Stainless Steel Sheet & Plate from TISCO POSCO
Products Specification
| Products Name | 439 Stainless Steel Sheet |
| Standard | ASTM EN JIS GB BIS |
| Thickness | 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm |
| Surface | 2B 2D or process other surface as request |
| Standard Size | 1219*2438mm 1000*2000mm |
| Service | Slit Cutting, bending , surface treatment |
| Other Grade | 200 Series: 201 202 |
| 300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347 | |
| 400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446 | |
| Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy | |
| MOQ | 500 kgs |
| Packing | Wooden Pallets and waterproof paper |
1.4510 (439) Sheet and Plate
Stainless steel producers have an ongoing programme of development designed to produce new grades. These new grades are sometimes developed for specific end uses and sometimes to improve upon an existing grade.
Type 1.4510 spans both of these two areas since it was developed for a particular range of applications in certain industries where it can be used in place of type 1.4301 (304). On some aspects, its properties and performance in service are actually superior to 304 whilst on others it falls between 430 and 304. Notably however, it is also lower cost than 304.
Type 1.4510 can be referred to as a 'Super-Ferritic'
Features:
~ Good for Deep Drawing
~ Good Weldability
~ Good pitting corrosion resistance
~ Good brightness
~ Polishes well
Applications/Industries:
The main target sector is catering equipment to replace grade 304
Availability:
~ 1250mm & 1500mm wide
~ Thicknesses 0.5mm to 2.0mm
~ Finishes Bright Annealed or Polished
Chemical Composition
Spec: EN 10088-2:2005
1.4510 Steel
| Chemical Element | % Present |
|---|---|
| Carbon (C) | 0.0 - 0.05 |
| Chromium (Cr) | 16.00 - 18.00 |
| Titanium (Ti) | 0.50 - 0.80 |
| Manganese (Mn) | 0.0 - 1.00 |
| Phosphorous (P) | 0.0 - 0.04 |
| Silicon (Si) | 0.0 - 1.00 |
| Sulphur (S) | 0.0 - 0.02 |
| Iron (Fe) | Balance |
Properties
| Physical Property | Value |
|---|---|
| Density | 7.70 g/cm³ |
| Melting Point | 1505 °C |
| Thermal Expansion | 11.0 x10^-6 /K |
| Modulus of Elasticity | 220 GPa |
| Thermal Conductivity | 25.0 W/m.K |
| Electrical Resistivity | 0.60 x10^-6 Ω .m |
Spec: EN 10088-2:2005
Sheet & Plate - Up to 13.5mm Thick
| Mechanical Property | Value |
|---|---|
| Proof Stress | 230 Min MPa |
| Tensile Strength | 420-600 MPa |
| Elongation A50 mm | 23 Min % |
Alloy Designations
Stainless Steel Grade 1.4510 is similar to, but may not be a direct equivalent to:
Type 439
UNS S43035
Uginox F18TNb
Sometimes referred to as 430LX.
