Cold Rolled 347 Stainless Steel Sheet & Plate & Strip SS Sheet UNS S34700 Stainless Steel
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 309S 310S 317L 347 .etc |
| Minimum Order Quantity | 1 Ton |
| Price | 1200 -2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 200 Series 300 Series 400 Series |
|---|---|---|---|
| Thickness | 0.3 - 3.0mm | Tech | Cold Rolled |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B BA NO.1 NO.4 8K HL Color Finishing |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
| Highlight | 347 Stainless Steel Sheet,UNS S34700 Stainless Steel Sheet |
||
Product Description
Cold Rolled 347 Stainless Steel Sheet & Plate & Strip SS Sheet UNS S34700 Stainless Steel
The 347 stainless steel grade is a stabilized alloy, due to its columbium + tantalum component within. Ideal for long-term work life in high temperatures (800-1500ºF), 347 Stainless Steel is also resistant to intergranular corrosion in the chromium carbide precipitation range. High creep and stress rupture properties are part of their superior mechanical properties.
347 Stainless Steel Sheet Specification Chart
| Description | ASTM A240 / ASME SA240 Stainless Steel Plates, ASTM A240 Hot Rolled Stainless Steel Plates |
| Standard | ASTM, ASME, BS, DIN, EN |
| Material | 310S, 310, 309, 309S, 316, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, 304, 304L, |
| 302, 301, 201, 202, 403, 405, 409, 409L, 410, 410S, 420, 430, 631, 904L, Duplex, etc | |
| Specification | Cold rolled: 1219mm * 2438mm (4′ x 8′), 1219mm * 3048mm (4′ x 10′), 1220mm * 2440mm, 1250mm * 2500mm or as your requirement.
Hot rolled: 1500mm * 2000mm, 1000mm * 3000mm, 1500mm * 4000mm, 1500m * 6000mm or as your requiremnt. |
| Technique | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Etc. |
| Surface | 2B, 2D, BA, NO. 1, NO. 4, NO.8, 8K, Mirror, Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Thickness | 0.25-200mm, 0.3mm to 120mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm |
| Package | Standard Export Seaworthy Package, or as required. |
| Value Added Services | Cladding,Heat Treatment,Annealed, Pickling, Polish,Rolling,Cutting,Bending,Forging,Minor Fabrication Etc. |
| MTC |
Mill Test Certificate, Available as per EN 10204 3.1 |
Chemical Composition of 347h Stainless Steel Sheets
| Type | Grade | ASTM A240 Chemical Composition | |||||||||
| ASTM(A240M) | Others(JIS) | C | Si | Mn | P | S | Ni | Cr | Mo | Others | |
| Austenitic Steels | |||||||||||
| 347 | SUS347 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 9.0/13.0 | 17.0/19.0 | ― | Nb:10ʷC/1.00 | |
Sa240 347h Mechanical Properties Table
| Type | Mechanical Properties for Stainless Steel Plates, Stainless Steel Sheet | |||||||
| ASTM(A240M) | Others(JIS) | Tensile Properties | Hardness | |||||
| Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation (%) | HBW | HRBW | ||||
| Austenitic Steels | ||||||||
| 347 | SUS347 | ≥205 | ≥515 | ≥40 | ≤201 | ≤92 | ||
Astm A240 Gr 347 Strips Physical Properties
| Density ( g.cm-3 ) | 7.93 |
| Melting point (°C ) | 1400-1425 |
Applications
The 347 Stainless type is ideal for many high-temperature aeronautical applications, including aircraft component manufacturing such as aircraft collector rings and exhaust stacks. Other applications where 347 Stainless Steel is chosen are boilers, exhaust manifolds, jet engine parts, mufflers for large engines and other various welded parts.
