304 Stainless Steel Plate 2B Finish 0.4-80mm Thickness
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 304 304L 316L 310S 321 2205 2507 904L 254SMO.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 5000 - 7200 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 304 304L 316L 310S 321 2205 2507 904L 254SMO.etc |
|---|---|---|---|
| Thickness | 0.4 -80.0mm | Width | 1219mm 1500mm 1800mm 2000mm |
| Surface | NO.1 2B | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | 304 stainless steel plate 2B finish,stainless steel plate 0.4-80mm thickness,304 stainless steel sheet with warranty |
||
Product Description
Cold Rolled & Hot Rolled 304 Stainless Steel Sheet Plate 2B BA HL 8K NO.1 2D Finishing Alloy 304
Products Specification
| Products Name | 304 Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 317L, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,654SMO,253MA,2205,2507.etc |
| Thickness | 0.6 - 30.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Service | Laser Cutting |
| Form | Plate / sheet |
| Cutting Shape | Round , Square, or any special shape as request |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
PRODUCT INFORMATION
304 Stainless Steel Sheet & Plate
MATERIAL SPECIFICATION
-
Grade: 304 / UNS S30400 / EN 1.4301
-
Standard: ASTM A240 / ASTM A480 / ASME SA240
-
Form: Sheets (≤6mm thickness) & Plates (>6mm thickness)
-
Surface Finish:
-
2B: Smooth, bright cold-rolled finish (most common)
-
No. 4: Brushed/satin finish (architectural)
-
BA (Bright Annealed): Mirror-like reflective finish
-
#8 Mirror: High-polish reflective surface
-
HL: Hairline finish
-
Custom finishes available
-
KEY PROPERTIES
-
Composition (%):
-
Cr: 18.0–20.0 | Ni: 8.0–10.5 | C: ≤0.08 | Mn: ≤2.0 | Si: ≤1.0 | Fe: Balance
-
-
Mechanical Properties (Annealed Condition):
Property Value Tensile Strength ≥515 MPa (75,000 psi) Yield Strength ≥205 MPa (30,000 psi) Elongation ≥40% (in 50mm) Hardness (Rockwell) 70 HRB max -
Corrosion Resistance:
-
Excellent resistance to:
-
Organic chemicals, food acids, freshwater, and atmospheric corrosion
-
Oxidation up to 870°C (1600°F)
-
-
Limitation: Susceptible to chloride pitting (avoid marine/coastal exposure)
-
-
Physical Properties:
-
Density: 8.0 g/cm³ | Melting Point: 1400–1450°C | Magnetic Response: Non-magnetic (may become slightly magnetic after forming)
-
DIMENSIONAL RANGES
| Parameter | Range | |
|---|---|---|
| Thickness | Sheets: 0.3mm–6.0mm (0.012"–0.25") Plates: 6.0mm–150mm (0.25"–6") |
|
| Width | 600mm–2000mm (24"–78.7") | |
| Length | 1000mm–6000mm (39"–236") | |
| Coil Options | ID: 508mm (20") | OD: 1000–2000mm |
ADVANTAGES
-
Hygienic & FDA-Compliant: Ideal for food processing, pharmaceutical, and medical equipment.
-
Ease of Fabrication: Excellent weldability (TIG/MIG/Laser), formability, and machinability.
-
Aesthetic Versatility: Multiple finishes for architectural/decorative applications.
-
Cost-Effectiveness: Most widely used austenitic stainless grade.
TYPICAL APPLICATIONS
-
Food/Beverage: Tanks, conveyor systems, processing tables
-
Architecture: Elevator panels, wall cladding, column covers
-
Industrial: Chemical tanks, heat exchangers, machinery guards
-
Automotive: Exhaust components, trim parts
-
Consumer Goods: Sinks, cookware, appliance exteriors
QUALITY ASSURANCE
-
Mill Test Reports (MTRs) per EN 10204 3.1
-
Compliance: ASTM, ASME, ISO 9445 (tolerances)
-
Surface: Free of scale, pits, and rolling defects
HANDLING & STORAGE
-
Protect surfaces from scratches during transport (plastic film/papers recommended).
-
Store off-ground in dry, covered areas to prevent moisture trapping.
-
Passivation post-fabrication highly recommended to restore corrosion resistance.
